QY25K.65.2B 泵进出油布管 Pipes for oil return and oil drain
| 序号 | 零部件代号 | 名称 | 数量 | 备注 | |
| No | Part No. | Part Description | Q’ty | Remark | |
| 1 | 10123495 | 胶管接头 | Tube | 1 | |
| 2 | 20120021 | 接头体 | Tie-in | 2 | |
| 3 | 20430005 | 螺母 | Nut | 4 | |
| 4 | 20120053 | 卡套 | Cutting ferrule | 4 | |
| 5 | 20120063 | 接头体 | Tie-in | 3 | |
| 6 | 10122436 | 法兰总成 | Flange | 2 | |
| 7 | 10122778 | 胶管接头 | Tube | 1 | |
| 8 | 11210408 | 管夹 | Pipe clip | 4 | |
| 9 | 10123755 | 法兰总成 | Flange | 1 | |
| 10 | 10123756 | 法兰总成 | Flange | 1 | |
| 11 | QY25K.65.2-2 | 无缝管 | Seamless tube | 1 | |
| 12 | 10124910 | 胶管接头 | Tube | 2 | |
| 13 | 10126048 | 胶管接头 | Tube | 1 | |
| 14 | 10122412 | 法兰总成 | Flange | 1 | |
| 15 | JHWF25S-03 | 法兰总成 | Flange | 2 | |
| 16 | 10120651 | 接头体 G10 | Tie-in G10 | 1 | |
| 17 | 10440016 | 塾圏 14 | Washer 14 | 1 | |
| 18 | QY25K.65.2.3 | 法兰总成 | Flange | 1 | |
| 19 | 10440006 | 塾圈 10 | Washer 10 | 8 | |
| 20 | 10420070 | 螺钉 M10×35 | Bolt M10×35 | 8 | |
| 21 | 10130423 | O形圈 41.2×3.55G | O seal ring 41.2×3.55G | 1 | |
| 22 | 低压胶管 Ø45×57 | Hose Ø45×57 | 1 | ||
| 23 | 11210186 | 喉箍 Ø44~Ø64 | Clamp Ø44~Ø64 | 4 | |
| 24 | 10440010 | 垫圈 12 | Washer 12 | 8 | |
| 25 | 10410043 | 螺栓 M12×35 | Bolt M12×35 | 8 | |
| 26 | 10130104 | O形圈 48.7×2.65G | O seal ring 48.7×2.65G | 1 | |
| 27 | QY25K.65.2.5A | 吸油管总成 | Flange | 1 | |
| 28 | QY25K.65.2-1 | 无缝管 | Seamless tube | 1 | |
| 29 | 低压胶管 Ø51×64 | Hose Ø51×64 | 1 | ||
| 30 | 11210345 | 喉箍 (Ø51~Ø70) | Clamp (Ø51~Ø70) | 4 | |
| 31 | 10130272 | O形圈 56×3.55G | O seal ring 56×3.55G | 1 | |
| 32 | QY25K.65.2.7 | 法兰总成 | Flange | 1 | |
| 33 | 低压胶管 Ø76×90 | Hose Ø76×90 | 1 | ||
| 34 | 11210313 | 喉箍 (Ø76~Ø92) | Clamp (Ø76~Ø92) | 4 | |
| 35 | 10130102 | O形圈 97.5×3.55G | O seal ring 97.5×3.55G | 1 | |
| 36 | QY25K.65.2.4 | 法兰总成 | Flange | 1 | |
| 37 | 10125013 | 胶管接头 | Tube | 1 | |
