XZ25K.57A 后轴 Real Axle
| 序号 | 零部件代号 | 名称 | 数量 | 备注 | |
| No | Part No. | Part Description | Q’ty | Remark | |
| 1 | XZ16K.56-1A | 端直通接头体 | End straight connector | 2 | |
| 2 | 10440018 | 塾圈 16 | Washer 16 | 4 | |
| 3 | 10120341 | 卡套 14 | Clip-knot 14 | 2 | |
| 4 | 10121953 | 螺母 E14 | Nut E14 | 2 | |
| 5 | 10120534 | 接头体 G14 | Connection G14 | 2 | |
| 6 | 10440029 | 垫圈 10 | Washer 10 | 2 | |
| 7 | 10410246 | 螺栓 M10×1 | Bolt M10×1 | 1 | |
| 8 | 10120724 | 接头 E6 | Connection E6 | 1 | |
| 9 | 10124653 | 胶管接头 | Rubber hose connector | 2 | |
| 10 | XZ16K.56-3A | 端直通接头体 | End straight connection | 2 | |
| 11 | 18/20TMRF-C223BD | 贯通驱动桥 | Transfixion drive axle | 1 | |
