XZ25K.51IIA 油泵装置 Oil Pump Assembly
| 序号 | 零部件代号 | 名称 | 数量 | 备注 | |
| No | Part No. | Part Description | Q’ty | Remark | |
| 1 | 10410038 | 螺铨 M10×30 | Bolt M10×30 | 10 | |
| 2 | 10430004 | 螺母 M10 | Nut M10 | 10 | |
| 3 | 10440006 | 塾圏 10 | Washer 10 | 13 | |
| 4 | 10310567 | 传动轴 L=880±20 | Propeller L=880±20 | 1 | |
| 5 | 10430021 | 螺栓 M10×25 | Bolt M10×25 | 3 | |
| 6 | XZ16K.51-1 | 轴头盖 | Shaft head cover | 1 | |
| 7 | XZ16K.51-2 | 油泵法兰盘 | Oil pump flange disc | 1 | |
| 8 | 10410117 | 螺栓 M14×50 | Bolt M14×50 | 4 | |
| 9 | 10440025 | 塾圈 14 | Washer 14 | 4 | |
| 10 | 10430026 | 螺母 M14 | Nut M14 | 4 | |
| 11 | 10440164 | 垫圈 14 | Washer 14 | 4 | |
| 12 | XZ25K.51II.1A | 泵架焊接 | Oil pump support | 1 | |
| 13 | CB-KPZH63/50/32/08 | 油泵(右旋) | Oil pump | 1 | |
| 14 | CB-KPZH50/32/32/08 | 油泵(右旋) | Oil pump | 1 | |
| 15 | XZ25K.51II.2A | 支架 | Support | 1 | |
| 16 | 10440009 | 塾圈 10 | Washer 10 | 6 | |
| 17 | XZ16K.51-4 | 板 | Plate | 1 | |
| 18 | 10410869 | 螺栓 M12×75 | Bolt M12×75 | 2 | |
| 19 | 10430005 | 螺母 M12 | Nut M12 | 4 | |
