XZ25K.50II 变速箱安装 Gear Box Assembly
| 序号 | 零部件代号 | 名称 | 数量 | 备注 | |
| No | Part No. | Part Description | Q’ty | Remark | |
| 1 | 10410406 | 螺柱 M10×70 | Bolt M10×70 | 12 | |
| 2 | 10440006 | 势圏 10 | Washer 10 | 28 | |
| 3 | 10430004 | 螺母 M10 | Nut M10 | 28 | |
| 4 | 10440012 | 垫圈 12 | Washer 12 | 9 | |
| 5 | 10470302 | 销 4×24 | Pin 4×24 | 1 | |
| 6 | 10470084 | 销 B12×35 | Pin B12×35 | 3 | |
| 7 | S6-120 | 变速箱 | Transmission | 1 | |
| 8 | XZ16K.50.1.1C | 分泵支架 | Clutch port |
1 | |
| 9 | 10100252 | 电磁阀总成 | Clutch servo cylinder | 1 | |
| 10 | XZ16K.41.2-1A | 接头体 | Connection Body | 3 | |
| 11 | 10440017 | 垫圈 12 | Washer 12 | 4 | |
| 12 | 10120611 | 螺塞 M12×1.5 | Bolt M12×1.5 | 1 | |
| 13 | CP1604GE010 | 离合器分泵 | Clutch servo cylinder | 1 | |
| 14 | XZ16K.50-6B | 接头 | Connection Body | 1 | |
| 15 | 10440016 | 垫圈 14 | Washer 14 | 1 | |
| 16 | XZ16K.50-7 | 桐管 Ø8×1L=3800 | Tube Ø8×1L=3800 | 1 | |
| 17 | 10430122 | 螺母 A8 | Nut A8 | 2 | |
| 18 | 10120552 | 管套 M12×50 | Bolt M12×50 | 2 | |
| 19 | XZ16K.50.4A | 斜撑 | Support | 2 | |
| 20 | 10410006 | 螺栓 M16×35 | Bolt M16×35 | 8 | |
| 21 | 10440002 | 垫圈 16 | Washer 16 | 10 | |
| 22 | 680590095 | 软垫 | Support | 2 | |
| 23 | XZ16K.50.3A | 支架 | Support | 4 | |
| 24 | XZ25K.50n.1 | 支架 | Support | 1 | |
| 25 | 10410234 | 螺柱 M12×35 | Bolt M12×35 | 12 | |
| 26 | JL420IC | 离合器 | Clutch | 1 | |
