XZ20_53III 传动轴 Propeller Shaft
| 序号 | 代号 | 名称 | 数量 | 备注 | |
| № | Part No. | Part Description | Q’ty | Remark | |
| 1 | XZ20.53III.1 | 传动轴前段 | First transmission axle | 1 | |
| 2 | 10410158 | 螺栓 M16×1.5×47 | Bolt M16×1.5×47 | 40 | |
| 3 | 10430003 | 螺母 M16×1.5 | Nut M16×1.5 | 40 | |
| 4 | 10410077 | 螺栓 M14×45 | Bolt M14×45 | 2 | |
| 5 | 10440025 | 垫圈 14 | Washer 14 | 2 | |
| 6 | 10440137 | 垫圈 14 | Washer 14 | 2 | |
| 7 | 10440164 | 垫圈 14 | Washer 14 | 2 | |
| 8 | 10430026 | 螺母 M14 | Nut M14 | 2 | |
| 9 | XZ20.53.1C | 中桥传动轴 | Second transmission axle | 1 | |
| 10 | XZ16K.53.4 | 后桥传动轴 | Last transmission axle | 1 | |
