XZ20_51C 油泵装置 Oil Pump Assembly
| 序号 | 代号 | 名称 | 数量 | 备注 | |
| № | Part No. | Part Description | Q’ty | Remark | |
| 1 | 10410038 | 螺栓 M10×30 | Bolt M10×30 | 10 | |
| 2 | 10440006 | 垫圈 10 | Washer 10 | 11 | |
| 3 | 10430004 | 螺母 M10 | Nut M10 | 14 | |
| 4 | 10310355 | 传动轴 | Propeller | 1 | |
| 5 | 10430021 | 螺栓 M10×25 | Bolt M10×25 | 1 | |
| 6 | 03000286 | 轴头盖 | Shaft head cover | 1 | |
| 7 | 11410697 | 接盘 | Linker | 1 | |
| 8 | 09151012 | 泵架 | Support | 1 | |
| 9 | 10410285 | 螺栓 M14×50 | Bolt M14×50 | 4 | |
| 10 | 10430026 | 螺母 M14 | Nut M14 | 4 | |
| 11 | 10440164 | 垫圈 14 | Washer 14 | 5 | |
| 12 | 10440025 | 垫圈 14 | Washer 14 | 9 | |
| 13 | 10100133 | 油泵 | Oil Pump | 1 | |
| 14 | 10410101 | 螺栓 M14×35 | Bolt M14×35 | 5 | |
| 15 | 10410669 | 螺栓 M10×70 | Bolt M10×70 | 2 | |
| 16 | 09451011 | 板 | Board | 1 | |
| 17 | 09451012 | 板 | Board | 1 | |
| 18 | 10440009 | 垫圈 10 | Washer 10 | 4 | |
