XZ20_50_1 离合器分泵安装 Clutch Wheel Cylinder Assembly
| 序号 | 代号 | 名称 | 数量 | 备注 | |
| № | Part No. | Part Description | Q’ty | Remark | |
| 1 | 10440012 | 垫圈 12 | Washer 12 | 1 | |
| 2 | 10470302 | 销 4×24 | Pin 4×24 | 1 | |
| 3 | 10470084 | 销轴 B12×35 | Pin B12×35 | 1 | |
| 4 | 10420004 | 螺栓 M12×25 | Bolt M12×25 | 4 | |
| 5 | 10440010 | 垫圈 12 | Washer 12 | 4 | |
| 6 | 10100120 | 离合器分泵 CQJH90 | Clutch wheel cylinder CQJH90 | 1 | |
| 7 | XZ20.50.1.1 | 分泵支架 | Clutch wheel cylinder support | 1 | |
| 8 | 10430004 | 螺母 M10 | Nut M10 | 4 | |
| 9 | 10430021 | 螺栓 M10×25 | Bolt M10×25 | 4 | |
| 10 | 10440006 | 垫圈 10 | Washer 10 | 4 | |
