XZ20_45II 发动机安装 Engine Install
| 序号 | 代号 | 名称 | 数量 | 备注 | |
| № | Part No. | Part Description | Q’ty | Remark | |
| 1 | 10410011 | 螺栓 M8×20 | Bolt M8×20 | 8 | |
| 2 | 10440001 | 垫圈 8 | Washer 8 | 8 | |
| 3 | 10440062 | 垫圈 8 | Washer 8 | 8 | |
| 4 | 09145021 | 导风罩 | Air guide cover | 1 | |
| 5 | 11210186 | 喉箍 Ø44〜Ø64 | Clip Ø44〜Ø64 | 8 | |
| 6 | 11412738 | 异型胶管 | Rubber hose | 1 | |
| 7 | XZ16C_45III-1 | 胶管内径 Ø55 L=120 | Rubber hose Ø55 L=120 | 4 | |
| 8 | 10610067 | 放水开关 | Water switch | 1 | |
| 9 | XZ16C_46_11I | 燃油管 | Fuel hose | 1 | |
| 10 | 11210218 | 喉箍 Ø10〜Ø16 | Clip Ø10〜Ø16 | 4 | |
| 11 | 10410138 | 螺栓 M14×1.5×35 | Bolt M14×1.5×35 | 2 | |
| 12 | 10440016 | 垫圈 14 | Washer 14 | 4 | |
| 13 | 11210905 | 尼龙扎带 | Bandage | 12 | |
| 14 | XZ16C_45III_2 | 进油管 I | Fuel hose I | 1 | |
| 15 | XZ25K_45III_4B | 燃油管 | Fuel hose | 1 | |
| 16 | XZ20_45II_7 | 燃油过滤器安装 | Fuel filter assembly | 1 | |
| 17 | XZ16C_45III_7 | 前支架 | Front support | 2 | |
| 18 | 10410101 | 螺栓 M14×35 | Bolt M14×35 | 8 | |
| 19 | 11210550 | T型抱箍 Ø92 | Clip Ø92 | 8 | |
| 20 | 10410058 | 螺栓 M10×35 | Bolt M10×35 | 4 | |
| 21 | 10440006 | 垫圈 10 | Washer 10 | 4 | |
| 22 | 10440009 | 垫圈 10 | Washer 10 | 4 | |
| 23 | 10430004 | 螺母 M10 | Nut M10 | 4 | |
| 24 | XZ16C_45III_8 | 下水管 I | Down water pipe I | 1 | |
| 25 | XZ16C_45III_10 | 下水管 II | Down water pipe II | 1 | |
| 26 | XZ16C_45-11 | 胶管内径 Ø50 L=120 | Rubber hose Ø50 L=120 | 2 | |
| 27 | 10440010 | 势圈 12 | Washer 12 | 12 | |
| 28 | 10420004 | 螺栓 M12×25 | Bolt M12×25 | 4 | |
| 29 | 11210404 | 软垫 | Rubbe support | 2 | |
| 30 | 10440012 | 垫圈 12 | Washer 12 | 12 | |
| 31 | 10410163 | 螺栓 M12×1.5×30 | Bolt M12×1.5×30 | 8 | |
| 32 | XZ16C.45.19 | 后支架 | Rear support | 2 | |
| 33 | 10410288 | 螺栓 M14×1.5×30 | Bolt M14×1.5×30 | 8 | |
| 34 | 10440025 | 垫圈 14 | Washer 14 | 16 | |
| 35 | XZ16C_45III-11 | 继电器支架 | Support | 1 | |
| 36 | 10000054 | 发动机 | Engine | 1 | |
| 37 | XZ35K5_45_5 | 下水管 | Down water pipe | 1 | |
| 38 | XZ16C_45III-9 | 弯板 | Plate | 2 | |
| 39 | XZ16K_45_14-1 | 弯带 | Plate | 2 | |
| 40 | 10430001 | 螺母 M8 | Nut M8 | 4 | |
| 41 | XZ20_45II_6 | 发动机上排气管安装 | Exhaust pipe assembly | 1 | |
| 42 | XZ20_45II_4 | 中冷器进气管 I | Tubing inlet pipe I | 1 | |
| 43 | XZ16C_45-2 | 胶管内径 Ø80 L=120 | Rubber hose Ø80 L=120 | 4 | |
| 44 | XZ20.45III.5 | 中冷器进气管 II | Tubing inlet pipe II | 1 | |
| 45 | XZ16C.45III.15 | 中冷器出气管 | Tubing outlet pipe | 1 | |
