XZ16K_41_7 贮气筒安装 Air Reservoir Assembly
| 序号 | 代号 | 名称 | 数量 | 备注 | |
| № | Part No. | Part Description | Q’ty | Remark | |
| 1 | 10410011 | 螺栓 M8×20 | Bolt M8×20 | 3 | |
| 2 | 10440001 | 垫圈 8 | Washer 8 | 3 | |
| 3 | 03000090 | 贮气筒支架 | Air Reservoir Support | 1 | |
| 4 | 10710011 | 贮气筒安装 | Air Reservoir Assembly | 1 | |
| 5 | 10440024 | 垫圈 22 | Washer 22 | 3 | |
| 6 | 10120263 | 釀塞 M22×1.5 | Screw Plug M22×1.5 | 1 | |
| 7 | 11410735 | 接头体 | Connection | 1 | |
| 8 | 10100079 | 放水阀 | Drip Valve | 1 | |
