XZ16C_67III 空滤器安装 Air Filter Assembly
| 序号 | 代号 | 名称 | 数量 | 备注 | |
| № | Part No. | Part Description | Q’ty | Remark | |
| 1 | XZ16C.67III-1 | 胶管内径 Ø100-140 | Rubber pipe Ø100-140 | 2 | |
| 2 | 11ZH4-9921 | T型抱箍 Ø112 | T-hoop Ø112 | 4 | |
| 3 | XZ16C.67III-3 | 支架 | Support | 1 | |
| 4 | XZ16C.67III-4 | 夹箍 | Clip | 1 | |
| 5 | 10430021 | 螺栓 M10×25 | Bolt M10×25 | 2 | |
| 6 | 10440009 | 垫圈 10 | Washer 10 | 6 | |
| 7 | 10430004 | 螺母 M10 | Nut M10 | 6 | |
| 8 | 10440006 | 垫圈 10 | Washer 10 | 6 | |
| 9 | XZ16C.67III.2 | 进气管 | Inlet air pipe | 1 | |
| 10 | XZ16C.67III-5 | 支架 | Support | 2 | |
| 11 | XZ16C.67III.6 | 紧固带 | Fix belt | 2 | |
| 12 | AH19051-C | 空滤器 | Air filter | 1 | |
| 13 | 10410010 | 螺栓 M8×25 | Bolt M8×25 | 2 | |
| 14 | 10440001 | 垫圈 8 | Washer 8 | 2 | |
| 15 | 10430001 | 螺母 M8 | Nut M8 | 2 | |
