QY25K5 – 20200064 主机总成 Mainframe Unit
| 序号 | 零部件代号 | 名称 | 数量 | 备注 | |
| Sr, No. | Part No. | Part name | Q’ ty | Remark | |
| 1 | 10220347 | HC4900 主机上盖 | Mainframe top lap | 1 | |
| 2 | 10220348 | HC4900 机壳总成 | Enclosure unit | 1 | |
| 3 | 10220349 | 钥匙开关总成 | Key switch unit | 1 | |
| 4 | 10220350 | 钥匙开关标牌 | Key switch caution plate | 1 | |
| 5 | 10220351 | HC4900 主机主板总成 | Mainframe mainboard | 1 | |
| 6 | 10220352 | 主机支脚 | Mainframe bracing | 4 | |
| 7 | 10220353 | 标牌 | Caution plate | 1 | |
| 8 | 10220354 | 试串口总成 | Series interface unit | 1 | |
| 9 | 10220355 | 间隔销 M5×15 | Intervallic stud M5×15 | 6 | |
| 10 | 10220356 | HC4900 机壳背板 | HC4900 enclosure back plate | 1 | |
| 11 | 10420012 | 螺钉 M5×10 | Bolt M5×10 | 16 | |
| 12 | 10420081 | 螺栓 M5×16 | Bolt M5×16 | 4 | |
| 13 | 10430002 | 螺母 M5 | Nut M5 | 4 | |
| 14 | 10440112 | 大垫圈 Ø5 | Big washer Ø5 | 4 | |
| 15 | 10420054 | 螺钉 M5×25 | Bolt M5×25 | 4 | |
| 16 | 10440133 | 垫圈 Ø5 | Washer Ø5 | 4 | |
| 17 | 10220358 | PG 接头 PG11 | PG socket PG11 | 1 | |
| 18 | 10220359 | 内齿垫圈 I 19 | Internally toothed washer I 19 | 1 | |
| 19 | 10220360 | 锁紧螺母 PG11 | Lock nut PG11 | 1 | |
| 20 | 10220361 | PG 接头 PG13.5 | PG socket PG13.5 | 2 | |
| 21 | 10220362 | 内齿垫圈 I 21 | Internally toothed washer I 21 | 2 | |
| 22 | 10220363 | 锁紧螺母 PG13.5 | Lock nut PG13.5 | 2 | |
| 23 | 10220364 | PG 接 头 PG7 | PG socket PG7 | 1 | |
| 24 | 10220365 | 螺母 PG7 | Nut PG7 | 1 | |
| 25 | 10220366 | 尼龙螺母 PG11 | Nylon nut PG11 | 1 | |
| 26 | 10220367 | 尼龙堵头 PG11 | Nylon cap PG11 | 1 | |
| 27 | 10220368 | 集成电路 | Integrated circuit | 2 | |
| 28 | 10220369 | 集成电路 | Integrated circuit | 1 | |
| 29 | 10220370 | 密封条 Y153 | Weather strip Y153 | 1 | |
| 30 | 12060613 | 三芯插头 | Plug | 13 | |
| 31 | 10220372 | 四芯插头 | Plug | 1 | |
| 32 | 10220373 | 外齿垫圈 Ø5 | Outside toothed washer Ø5 | 16 | |
| 33 | 10220374 | 尼龙锁紧螺母 PG7 | Nylon lock nut PG7 | 1 | |
| 34 | 10220375 | 尼龙堵头 PG7 | Nylon cap PG7 | 1 | |
