QY25K5 – 11410913 起重钩 Hook
| 序号 | 零部件代号 | 名称 | 数量 | 备注 | |
| Sr, No. | Part No. | Part name | Q’ ty | Remark | |
| 1 | 12102814 | 挡板 | Plate | 1 | |
| 2 | 12102815 | 弹簧 | Spring | 1 | |
| 3 | 12102816 | 吊钩 | Hook | 1 | |
| 4 | 10470314 | 销轴 B8×75 | Pin shaft B8×75 | 1 | |
| 5 | 10470001 | 销 3.2×20 | Pin 3.2×20 | 1 | |
| 6 | 10440062 | 垫圈 8 | Washer 8 | 1 | |
| 7 | 12104813 | 横梁 | Cross beam | 1 | |
| 8 | 10510093 | 轴承 51317 | Bearing 51317 | 1 | |
| 9 | 10460052 | 铆钉 3×6 | Rivet 3×6 | 1 | |
| 10 | 10810011 | 油杯 M8×1 | Glib M8×1 | 1 | |
| 11 | 11415100 | 标牌 | Scutcheon | 1 | |
| 12 | 12102818 | 圆螺母 | Nut | 1 | |
| 13 | 10810006 | 油杯 M10×1 | Glib M10×1 | 1 | |
| 14 | 12102819 | 防松板 | Plate | 1 | |
| 15 | 10410043 | 螺栓 M12×35 | Bolt M12×35 | 1 | |
| 16 | 10440010 | 垫圈 12 | Washer 12 | 1 | |
| 17 | 12104814 | 外侧板 | Plate | 2 | |
| 18 | 12102944 | 隔环 | Separate ring | 8 | |
| 19 | 12104816 | 滑轮轴 | Pulley shaft | 1 | |
| 20 | 11412000 | 滑轮 | Pulley | 5 | |
| 21 | 12104817 | 右内侧板 | Plate | 1 | |
| 22 | 12104818 | 左内侧板 | Plate | 1 | |
| 23 | 12104819 | 杆 | Staff | 4 | |
| 24 | 12104820 | 钢管 Ø40×41=192 | Steel tube Ø40×41=192 | 4 | |
| 25 | 12102954 | 防护板 | Plate | 4 | |
| 26 | 12104822 | 钢管 Ø40×41=46 | Steel tube Ø40×41=46 | 2 | |
| 27 | 12104823 | 钢管 Ø40×41=57 | Steel tube Ø40×41=57 | 4 | |
| 28 | 10440015 | 垫圈 20 | Washer 20 | 4 | |
| 29 | 10430008 | 螺母 M20 | Nut M20 | 4 | |
| 30 | 12104824 | 钢管 Ø40×41=69 | Steel tube Ø40×41=69 | 4 | |
| 31 | 12102953 | 导绳块 | Guide rope | 5 | |
| 32 | 12104826 | 垫圈 | Washer | 12 | |
| 33 | 10470235 | 销 3.2×40 | Pin 3.2×40 | 6 | |
| 34 | 12104827 | 销 | Pin | 2 | |
| 35 | 12104828 | 防护装置 | Guard | 4 | |
| 36 | 12104829 | 防护装置 | Guard | 2 | |
| 37 | 10510033 | 轴承 6215-Z | Bearing 6215-Z | 10 | |
| 38 | 10430008 | 螺母 M20 | Nut M20 | 4 | |
| 39 | 10450024 | 挡圈 130 | Retaining ring 130 | 5 | |
