QY25K5 – 10260304 控制板总成 Control plate assembly
| 序号 | 零部件代号 | 名称 | 数量 | 备注 | |
| Sr, No. | Part No. | Part name | Q’ ty | Remark | |
| 1 | 10240095 | 十五路熔断器 | Fuse | 1 | |
| 2 | 12055371 | 熔断器说明 | Fuse assembly instruction | 1 | |
| 3 | 10420255 | 螺钉 M5×12 | Bolt M5×12 | 2 | |
| 4 | 10440232 | 垫圈 5 | Washer 5 | 2 | |
| 5 | 10440231 | 垫圈 5 | Washer 5 | 2 | |
| 6 | 10430002 | 螺 母 | Nut M5 | 2 | |
| 7 | 10240174 | 一路熔断器 | Fuse | 1 | |
| 8 | 10220333 | 继电器 | Relay | 1 | |
| 9 | 10240064 | 继电器 | Relay | 8 | |
| 10 | 10240126 | 闪光继电器 | Relay | 3 | |
| 11 | 12104778 | 控制板线束 | Control plate assembly wire | 1 | |
| 12 | 10200184 | 蜂鸣器 | Warning buzzer | 1 | |
| 13 | 10210035 | 蜂鸣器 | Warning buzzer | 1 | |
| 14 | 20240148 | 继电器 | Relay | 2 | |
| 15 | 20240149 | 继电器座 | Relay socket | 2 | |
| 16 | 10420254 | 螺钉 M5×10 | Bolt M5×10 | 15 | |
| 17 | 12104779 | 控制板支架 | Control plate support | 1 | |
