QY25K5 – 10220270 配重电气 Balance Electric System
| 序号 | 零部件代号 | 名称 | 数量 | 备注 | |
| Sr, No. | Part No. | Part name | Q’ ty | Remark | |
| 1 | 01200824 | 示廓灯支架 | Outline lamp support | 2 | |
| 2 | 10200075 | 后示廓灯 | Outline lamp | 2 | |
| 3 | 30249014 | 汽胶线 L= 10m | Wire L= 10m | 1 | |
| 4 | 10410678 | 螺栓 M6×20 | Bolt M6×20 | 8 | |
| 5 | 10440021 | 垫圈 6 | Washer 6 | 8 | |
| 6 | 10420222 | 螺钉 M6×10 | Bolt M6×10 | 2 | |
| 7 | 10230040 | 片形孔式接头 | Sheet plug | 2 | |
| 8 | 10420099 | 螺钉 M6×15 | Bolt M6×15 | 4 | |
| 9 | 11210544 | 管夹 | Pipe clip | 4 | |
| 10 | 10220275 | 平衡重电气件焊接图 | Balance electric system welded construction | 1 | |
| 11 | 10200195 | 吸盘式弹头警示灯 | Caution lamp | 2 | |
