QY25K5 – 10210025 长度角度传感器总成 Length and Angle Sensor Unit
| 序号 | 零部件代号 | 名称 | 数量 | 备注 | |
| Sr, No. | Part No. | Part name | Q’ ty | Remark | |
| 1 | 10220392 | 测长壳体上盖 | Casing top lap | 1 | |
| 2 | 10220393 | 测角总成 | Clinometer unit | 1 | |
| 3 | 10220394 | 测长电位器单元 | Regulation-resistance unit | 1 | |
| 4 | 10220395 | 滑环总成 | Slip ring unit | 1 | |
| 5 | 10220396 | 电压电流转换板总成 | U / I converter plate unit | 1 | |
| 6 | 10220397 | 卷簧 | Spiral spring | 1 | |
| 7 | 10220398 | 弹簧核轮 | Spring checking wheel | 2 | |
| 8 | 10220399 | 测长壳体 | Casing | 1 | |
| 9 | 10220400 | 测长线 | Wire | 1 | |
