QY25K5 – 01811015 操纵室电气 Operating Cabs Electric System
| 序号 | 零部件代号 | 名称 | 数量 | 备注 | |
| Sr, No. | Part No. | Part name | Q’ ty | Remark | |
| 1 | 10260293 | 仪表箱总成 | Control box assembly | 1 | |
| 2 | 10210092 | 显示器 | Display | 1 | |
| 3 | 10410583 | 螺栓 M6×25 | Bolt M6×25 | 8 | |
| 4 | 10430009 | 螺母 M6 | Nut M6 | 16 | |
| 5 | 10440022 | 垫圈 6 | Washer 6 | 12 | |
| 6 | 10440021 | 垫圈 6 | Washer 6 | 12 | |
| 7 | 10420326 | 螺钉 M3×15 | Bolt M3×15 | 6 | |
| 8 | 10440183 | 垫圈 3 | Washer 3 | 6 | |
| 9 | 12104774 | 操纵室线束 | Operating cabs wiers | 1 | |
| 10 | 12104775 | 音响线束 | Acoustic wiers | 1 | |
| 11 | 12054516 | 操纵说明 I | Control instruction I | 1 | |
| 12 | 10260298 | 右控制器 | Right controller | 1 | |
| 13 | 10410487 | 螺栓 M5×16 | Bolt M5×16 | 12 | |
| 14 | 10440133 | 垫圈 5 | Washer 5 | 12 | |
| 15 | 10210106 | 力矩限制器 | Moment limiter body | 1 | |
| 16 | 10260299 | 左控制器 | Left controller | 1 | |
| 17 | 12054517 | 操纵说明 II | Control instruction II | 1 | |
| 18 | 10260300 | 控制板总成 | Control plate assembly | 1 | |
| 19 | 10440112 | 垫圈 5 | Washer 5 | 4 | |
| 20 | 20240056 | 脚踏开关 | Push Switch | 1 | |
| 21 | 11211385 | 扎带 | Clip strip | 50 | |
| 22 | 10230010 | 二芯插头护套 | The jacket of plug | 1 | |
| 23 | 10230292 | 单芯复合插头 | The jacket of plug | 1 | |
| 24 | 10230019 | 八芯插头护套 | The jacket of plug | 5 | |
| 25 | 10230087 | 六芯插头护套 | The jacket of plug | 5 | |
| 26 | 10230071 | 片式插接件插头 | Plug | 20 | |
| 27 | 10230072 | 片式插接件插座 | Socket | 20 | |
| 28 | 30249004 | 绝缘胶带 | Insulating tape | 1 | |
| 29 | 30249014 | 汽胶线 L=5m | Wire L=5m | 1 | |
| 30 | 11210123 | 扎帯 | Clip strip | 50 | |
| 31 | 10260286 | 脚踏控制器 | Pedal controller | 1 | 欧III发动机 EURO 3 engine |
| 32 | 10230231 | 三芯插头护套 | The jacket of plug | 1 | 欧III发动机 EURO 3 engine |
| 33 | 10410122 | 螺栓 M6×40 | Bolt M6×40 | 4 | 欧III发动机 EURO 3 engine |
| 34 | 10230327 | 片式插接件插头 | Plug | 3 | 欧III发动机 EURO 3 engine |
| 35 | 10430009 | 螺母 M6 | Nut M6 | 4 | |
| 36 | 10440021 | 垫圈 6 | Washer 6 | 4 | |
| 37 | 10440022 | 垫圈 6 | Washer 6 | 4 | |
| 38 | 10200808 | 三色警示灯 | Warning lamp | 1 | |
| 39 | 10200184 | 蜂鸣器 | Warning buzzer | 2 | |
