QY25K5 – 01811002 主臂电气 Boom Electric System
| 序号 | 零部件代号 | 名称 | 数量 | 备注 | |
| Sr, No. | Part No. | Part name | Q’ ty | Remark | |
| 1 | 10440021 | 垫圈 6 | Washer 6 | 40 | |
| 2 | 10440022 | 垫圈 6 | Washer 6 | 40 | |
| 3 | 10410001 | 螺栓 M6×14 | Bolt M6×14 | 40 | |
| 4 | 01811003 | 拉线支架 | Wire shelf | 1 | |
| 5 | 11211049 | 套环 | Loop | 1 | |
| 6 | 10260227 | 卸扣 | Buckle | 1 | |
| 7 | 11413699 | 绳夹 6KTH | Nip 6KTH | 2 | |
| 8 | 10210092 | 压线轮 I | Wheel wire control I | 3 | |
| 9 | 10210092 | 压线轮 II | Wheel wire control II | 2 | |
| 10 | 01811007 | 工作灯支架 | Working lamp support | 1 | |
| 11 | 10230096 | 圆柱型插头 | Columniform plug | 10 | |
| 12 | 10230093 | 圆柱型插接件护套 | The jacket of columniform plug | 10 | |
| 13 | 10230098 | 圆柱型插座 | Columniform socket | 10 | |
| 14 | 10230094 | 圆柱型插接件护套 | The jacket of columniform socket | 10 | |
| 15 | 10200021 | 工作灯 | Work lamp | 1 | |
| 16 | 01811008 | 线支架 | Wire support | 5 | |
| 17 | 10210025 | 长度、角度传感器 | Length and angle sensor | 1 | |
| 18 | 11210023 | 扎带 | Clip strip | 50 | |
| 19 | 10440064 | 垫圈 10 | Washer 10 | 4 | |
| 20 | 10410038 | 螺栓 M10×30 | Bolt M10×30 | 4 | |
| 21 | 10440009 | 垫圈 10 | Washer 10 | 6 | |
| 22 | 01811009 | 线卡 | Wire clip | 7 | |
| 23 | 12053655 | 接线盒总成 | Junction box unit | 1 | |
| 24 | 10420435 | 螺钉 M4×10 | Bolt M4×10 | 4 | |
| 25 | 10200170 | 警示灯 | Caution light | 1 | |
| 26 | 01811010 | 警示灯支架 | Caution light support | 1 | |
| 27 | 10230040 | 片形孔式接线片 | Sheet plug | 4 | |
| 28 | 10430002 | 螺母 M5 | Nut M5 | 2 | |
| 29 | 10440112 | 垫圈 5 | Washer 5 | 2 | |
| 30 | 30249122 | 热缩套管 L= 15 | Sleeve L= 15 | 8 | |
| 31 | 01811011 | 支架 | Bracket | 1 | |
| 32 | 30249032 | 二芯电缆 L= 15m | Cable L= 15m | 1 | |
| 33 | 10240038 | 高度限位开关 | Heigh limit switch | 1 | 带钢索配重 Taked tightwire banlancer |
| 34 | 10430004 | 螺母 M10 | Nut M10 | 2 | |
| 35 | 10230010 | 二芯插头护套 | The jacket of plug | 1 | |
| 36 | 10230071 | 片式插接件插头 | Sheet plug | · 2 | |
| 37 | 30249014 | 汽胶线 L= 5m | Wire L= 5m | 1 | |
| 38 | 30249014 | 汽胶线 L= 5m | Wire L=5m | 1 | |
| 39 | 30249004 | 绝缘胶带 | Insulating tape | 1 | |
| 40 | 30249096 | 三芯电缆 L= 3m | Cable L= 3m | 1 | |
| 41 | 01811018 | 顺序伸缩控制装置 | Sequential telescopic control device | 1 | |
| 42 | 11413174 | 风速仪 | Anemoscope | 1 | |
| 43 | 10470138 | 销 8×60 | Pin 8×60 | 1 | |
| 44 | 06111080 | 风速仪支架 | Support Anemoscope | 1 | |
