QY25K5 – 01802379 五节臂总成 5th Section
| 序号 | 零部件代号 | 名称 | 数量 | 备注 | |
| Sr, No. | Part No. | Part name | Q’ ty | Remark | |
| 1 | 01802380 | 五节臂结构 | 5 th Section Structure | 1 | |
| 2 | 01802432 | 绳挡 | Rope Hold | 3 | |
| 3 | 11412835 | 弹簧销 | Spring Pin | 6 | |
| 4 | 01802433 | 销轴 | Pin Shafte | 1 | |
| 5 | 01802434 | 隔套 | Sleeve | 1 | |
| 6 | 01802435 | 隔套 | Sleeve | 1 | |
| 7 | 01802436 | 盖板 | Cover Plate | 1 | |
| 8 | 01802437 | 挡轴板 | Retaining Plate | 4 | |
| 9 | 11413838 | 隔套 | Sleeve | 6 | |
| 10 | 01801308 | 滑轮总成 | Pulley Assemble | 5 | |
| 11 | 01802438 | 销轴 | Pin Shafte | 1 | |
| 12 | 01802439 | 隔套 | Sleeve | 1 | |
| 13 | 11415477 | 滑块 | Slider | 2 | |
| 14 | 01801154 | 销轴 | Pin Shafte | 2 | |
| 15 | 01802440 | 垫片 | Mat | 4 | |
| 16 | 01802441 | 垫片 | Mat | 2 | |
| 17 | 11415478 | 滑块 | Slider | 4 | |
| 18 | 01802442 | 连接块 | Conjecting Block | 4 | |
| 19 | 01802443 | 垫片 | Mat | 8 | |
| 20 | 01802444 | 垫片 | Mat | 4 | |
| 21 | 11415479 | 导轨 | Track | 2 | |
| 22 | 01801313 | 滑轮总成 | Pulley Assemble | 2 | |
| 23 | 10410026 | 螺栓 M8×16 | Bolt M8×16 | 2 | |
| 24 | 10440062 | 垫圈 8 | Washer 8 | 12 | |
| 25 | 10440001 | 垫圈 8 | Washer 8 | 2 | |
| 26 | 10410010 | 螺栓 M8×25 | Bolt M8×25 | 8 | |
| 27 | 10810006 | 油杯 M10×1 | Oil Cup M10×1 | 6 | |
| 28 | 10420092 | 螺栓 M8×16 | Bolt M8×16 | 6 | |
| 29 | 10420206 | 螺钉 M8×25 | Bolt M8×25 | 2 | |
| 30 | 10420196 | 螺栓 M8×50 | Bolt M8×50 | 2 | |
