QY25K5 – 01802259 二节臂总成 2nd Section
| 序号 | 零部件代号 | 名称 | 数量 | 备注 | |
| Sr, No. | Part No. | Part name | Q’ ty | Remark | |
| 1 | 01802260 | 二节臂结构 | 2nd Section Structure | 1 | |
| 2 | 11415455 | 板 | Plate | 1 | |
| 3 | 01802292 | 板 | Plate | 1 | |
| 4 | 11417039 | 螺 栓 | Bolt | 6 | |
| 5 | 01801079 | 支撑块 | Surport | 2 | |
| 6 | 11415456 | 滑块 | Slider | 2 | |
| 7 | 11415447 | 滑块 | Slider | 2 | |
| 8 | 11415448 | 滑块 | Slider | 2 | |
| 9 | 11415449 | 滑块 | Slider | 1 | |
| 10 | 11415457 | 滑块 | Slider | 2 | |
| 11 | 01801154 | 销轴 | Pin Shafte | 2 | |
| 12 | 01802293 | 垫片 | Mat | 4 | |
| 13 | 01802294 | 垫片 | Mat | 4 | |
| 14 | 11415458 | 滑块 | Slider | 4 | |
| 15 | 01801159 | 垫片 | Mat | 8 | |
| 16 | 01801160 | 垫片 | Mat | 8 | |
| 17 | 11415459 | 滑块 | Slider | 2 | |
| 18 | 01801161 | 垫片 | Mat | 4 | |
| 19 | 01801162 | 垫片 | Mat | 4 | |
| 20 | 11415460 | 板 | Plate | 2 | |
| 21 | 01802295 | 板 | Plate | 2 | |
| 22 | 11415461 | 滑块 | Slider | 2 | |
| 23 | 11415452 | 滑块 | Slider | 1 | |
| 24 | 11415453 | 滑块 | Slider | 1 | |
| 25 | 11415454 | 滑块 | Slider | 2 | |
| 26 | 01802258 | 垫板 | Mat | 6 | |
| 27 | 10420206 | 螺钉 M8×25 | Bolt M8×25 | 3 | |
| 28 | 10440062 | 垫圏 8 | Washer 8 | 1 | |
| 29 | 10440001 | 垫圈 8 | Washer 8 | 1 | |
| 30 | 10430001 | 螺母 M8 | Nut M8 | 1 | |
| 31 | 10430078 | 螺母 M16 | Nut M16 | 6 | |
| 32 | 10470133 | 销 B16×85 | Pin B16×85 | 4 | |
| 33 | 10470007 | 销 B4×30 | Pin B4×30 | 4 | |
| 34 | 10810006 | 油杯 M10×1 | Oil Cup M10×1 | 4 | |
| 35 | 10420206 | 螺钉 M8×25 | Bolt M8×25 | 12 | |
| 36 | 10440010 | 垫圈 12 | Washer 12 | 6 | |
| 37 | 10440123 | 垫圈 12 | Washer 12 | 6 | |
| 38 | 10410016 | 螺栓 M12×50 | Bolt M12×50 | 6 | |
