QY25K5 – 01802200 基本臂总成 Base boom
| 序号 | 零部件代号 | 名称 | 数量 | 备注 | |
| Sr, No. | Part No. | Part name | Q’ ty | Remark | |
| 1 | 01802201 | 基本臂结构 | Base boom structure | 1 | |
| 2 | 01801069 | 压绳滑轮 | Roller | 1 | |
| 3 | 11415445 | 板 | Plate | 1 | |
| 4 | 11417039 | 螺栓 | Bolt | 6 | |
| 5 | 01801079 | 支撑块 | Support | 2 | |
| 6 | 11415446 | 滑块 | Slider | 2 | |
| 7 | 11415447 | 滑块 | Slider | 2 | |
| 8 | 11415448 | 滑块 | Slider | 2 | |
| 9 | 11415449 | 滑块 | Slider | 3 | |
| 10 | 01801097 | 挡轴板 | Retaining plate | 1 | |
| 11 | 11413835 | 销轴 | Pin shafte | 1 | |
| 12 | 11413836 | 套 | Bushing | 2 | |
| 13 | 01801076 | 隔套 | Sleeve | 2 | |
| 14 | 11415450 | 板 | Plate | 1 | |
| 15 | 01802256 | 板 | Plate | 1 | |
| 16 | 11415451 | 板 | Plate | 2 | |
| 17 | 01802257 | 板 | Plate | 2 | |
| 18 | 11415452 | 滑块 | Slider | 1 | |
| 19 | 11415453 | 滑块 | Slider | 1 | |
| 20 | 11415454 | 滑块 | Slider | 8 | |
| 21 | 01802258 | 垫板 | Mat | 6 | |
| 22 | 10410040 | 螺栓 M12×40 | Bolt M12×40 | 2 | |
| 23 | 10440010 | 垫圈 12 | Washer 12 | 8 | |
| 24 | 10440123 | 垫圈 12 | Washer 12 | 10 | |
| 25 | 10430005 | 螺母 M12 | Nut M12 | 2 | |
| 26 | 10420206 | 螺 钉 M8×25 | Bolt M8×25 | 3 | |
| 27 | 10440062 | 垫圈 8 | Washer 8 | 1 | |
| 28 | 10440001 | 垫圈 8 | Washer 8 | 1 | |
| 29 | 10430001 | 螺 母 M8 | Nut M8 | 1 | |
| 30 | 10430078 | 螺 母 M16 | Nut M16 | 6 | |
| 31 | 10470133 | 销 B16×85 | Pin B16×85 | 4 | |
| 32 | 10470007 | 销 B4×30 | Pin B4×30 | 4 | |
| 33 | 10410324 | 螺栓 M20×40 | Bolt M20×40 | 2 | |
| 34 | 10440015 | 垫圈 20 | Washer 20 | 2 | |
| 35 | 10410016 | 螺栓 M12×50 | Bolt M12×50 | 6 | |
| 36 | 10420322 | 螺打 M8×10 | Bolt M8×10 | 3 | |
| 37 | 10500024 | 复合轴承 Ø98×Ø90×100 | Bearing Ø98×Ø90×100 | 2 | |
| 38 | 10810006 | 油杯 M10×1 | Oil Cup M10×1 | 2 | |
