QY25K.65.5A 前支腿配管 Pipes For Front Outrigger Oil
| 序号 | 零部件代号 | 名称 | 数量 | 备注 | |
| No | Part No. | Part Description | Q’ty | Remark | |
| 1 | 11010010 | 液压双向锁 | Double-way lock | 1 | |
| 2 | 10420001 | 螺栓 M10×45 | Bolt M10×45 | 4 | |
| 3 | 10440006 | 塑圈 10 | Washer 10 | 4 | |
| 4 | 10120651 | 接头体 G10 | Gonnection G10 | 2 | |
| 5 | 10440016 | 垫圈 14 | Washer 14 | 2 | |
| 6 | 10240073 | 压力继电器 | Hydraulic pressure switch | 1 | |
| 7 | 10121072 | 胶管接头 | Tube | 2 | |
| 8 | 10120540 | 接头体 G12 | Gonnection G12 | 4 | |
| 9 | 10120509 | 卡套 12 | Cutting ferrule 12 | 8 | |
| 10 | 10120510 | 螺母 G12 | Nut G12 | 8 | |
| 11 | 11210939 | 管卡 | Clip | 2 | |
| 12 | QY25K.65.5-1 | 无缝管 Ø12×1.5 | Seamless tube Ø12×1.5 | 1 | |
| 13 | QY25K.65.5-2 | 无缝管 Ø12×1.5 | Seamless tube Ø12×1.5 | 1 | |
| 14 | QY25K.65.5-4 | 无缝管 Ø12×1.5 | Seamless tube Ø12×1.5 | 1 | |
| 15 | QY25K.65.5-3 | 无缝管 Ø12×1.5 | Seamless tube Ø12×1.5 | 1 | |
| 16 | 11210337 | 管卡 | Clip | 2 | |
| 17 | 10120652 | 接头体 G12 | Gonnection G12 | 1 | |
| 18 | 10440018 | 垫圈 16 | Washer 16 | 1 | |
