QY20_66 液压油箱总成 Hydraulic Oil Tank
| 序号 | 代号 | 名称 | 数量 | 备注 | |
| № | Part No. | Part Description | Q’ty | Remark | |
| 1 | 11415173 | 油箱体 | Oil tank body | 1 | |
| 2 | 03000860 | 盖 | Cover | 1 | |
| 3 | 10140006 | 液位液温计 | Thermo-liquid meter | 1 | |
| 4 | 10440008 | 垫圈 33 | Washer 33 33 | 1 | |
| 5 | 10130010 | 螺塞 M33×2 | Screw stuff M33×2 | 1 | |
| 6 | 10410038 | 螺栓 M10×30 | Bolt M10X30 M10×30 | 4 | |
| 7 | 10440006 | 垫圈 10 | Washer 10 10 | 12 | |
| 8 | 10110008 | 液压空气滤清器 | Air cleaner | 1 | |
| 9 | 10420002 | 螺栓 M10×20 | Bolt M10X20 M10×20 | 8 | |
| 10 | 10440009 | 垫圈 10 | Washer 10 10 | 12 | |
| 11 | 10130321 | O形圈 212×5.3 | O seal ring 212X5 212×5.3 | 1 | |
| 12 | 10110074 | 回油滤油器 | Oil return filter | 1 | |
| 13 | 10110075 | 吸油滤网 | Oil return filter | 1 | |
