QY20_65_2B 泵进出油配管 Pipes for Pressure Oil
| 序号 | 代号 | 名称 | 数量 | 备注 | |
| № | Part No. | Part Description | Q’ty | Remark | |
| 1 | 09265871 | 吸油法兰总成 I | Flange I | 1 | |
| 2 | 09165835 | 法兰总成 | Flange | 1 | |
| 3 | 11211148 | 低压软管 Ø51×64 L=170 | Hose Ø51×64 L=170 | 1 | |
| 4 | 11211164 | 低压软管 Ø76×90 L=900 | Hose Ø76×90 L=900 | 1 | |
| 5 | 09265831 | 无缝管 Ø18×2 | Seamless tube Ø18×2 | 1 | |
| 6 | 09265832 | 无缝管 Ø22×3 | Seamless tube Ø22×3 | 1 | |
| 7 | 09265833 | 无缝管 Ø22 ×3 | Seamless tube Ø22 ×3 | 1 | |
| 8 | 09265873 | 吸油法兰总成 II | Flange II | 1 | |
| 9 | QY20_65_3-9A | 无缝管 Ø18×2 | Seamless tube Ø18×2 | 1 | |
| 10 | 09265838 | 无缝管 Ø6×1 | Seamless tube Ø6×1 | 1 | |
| 11 | 11412990 | 内护套 | Inner jacket | 2 | |
| 12 | 10130124 | O形圈 46.2×2.65G | O seal ring 46.2×2.65G | 2 | |
| 13 | 10410043 | 螺栓 M12×35 | Bolt M12×35 | 8 | |
| 14 | 10440010 | 垫圈 12 | Washer 12 | 8 | |
| 15 | 11210345 | 喉箍 (51-70) | Clamp (51-70) | 4 | |
| 16 | 20120021 | 管接头 | Connection | 1 | |
| 17 | 20120442 | 管接头 | Connection | 1 | |
| 18 | 11210107 | 喉箍 (70-89) | Clamp (70-89) | 4 | |
| 19 | 20121364 | 管接头 | Connection | 2 | |
| 20 | 20120005 | 管接头 | Connection | 2 | |
| 21 | 11210922 | 管夹 | Pipe clip | 4 | |
| 22 | 11210408 | 管夹 | Pipe clip | 3 | |
| 23 | 20120063 | 管接头 | Connection | 1 | |
| 24 | 20120062 | 管接头 | Connection | 2 | |
| 25 | 803102208 | 法兰 | Flange | 1 | |
| 26 | 803102207 | 法兰 | Flange | 2 | |
| 27 | 803102294 | 胶管接头 | Hose | 2 | |
| 29 | 803102295 | 胶管接头 | Hose | 1 | |
| 30 | 805000062 | 螺栓 M10×35 | Bolt M10×35 | 4 | |
| 31 | 805300014 | 垫圈 10 | Washer 10 | 4 | |
| 32 | 801100092 | O形圈 97.5×3.55G | O seal ring 97.5×3.55G | 1 | |
| 33 | 803102296 | 胶管接头 | Hose | 1 | |
| 34 | 803103247 | 胶管接头 | Hose | 1 | |
| 35 | 803101527 | 胶管接头 | Hose | 1 | |
| 36 | 803101720 | 管接头 G6 | Connection G6 | 1 | |
| 37 | 805300037 | 垫圈 10 | Washer 10 | 1 | |
| 38 | 803103290 | 法兰总成 | Flange assembly | 1 | |
| 39 | 803102760 | 法兰 | Flange | 2 | |
| 40 | 803102203 | 管接头 G6 | Connection G6 | 1 | |
| 41 | 803500382 | 压力表 | Press meter | 1 | |
| 42 | 805100351 | 螺钉 M4×20 | Bolt M4×20 | 3 | |
| 43 | 805300027 | 垫圈 4 | Washer 4 | 3 | |
| 44 | 805200082 | 螺母 M4 | Nut M4 | 3 | |
| 45 | 803102298 | 胶管接头 | Hose | 1 | |
| 46 | 801100166 | O形圈 15×2.65G | O seal ring 15×2.65G | 1 | |
