QY20_59A 活动支腿 Sliding Beam
| 序号 | 代号 | 名称 | 数量 | 备注 | |
| № | Part No. | Part Description | Q’ty | Remark | |
| 1 | 09459830 | 水平支腿 | Level Sliding Beam | 1 | |
| 2 | 11414698 | 销轴 | Pin Spindle | 1 | |
| 3 | 11414699 | 销 | Pin | 1 | |
| 4 | 11414692 | 销轴 | Pin Spindle | 1 | |
| 5 | 03001540 | 支座 | Plank | 1 | |
| 6 | QY16K_59-7 | 板 | Board | 1 | |
| 7 | 09159826 | 销轴组件 | Pin Spindle | 1 | |
| 8 | 10420004 | 螺栓 M12×25 | Bolt M12×25 | 4 | |
| 9 | 10410655 | 螺栓 M16×75 | Bolt M16×75 | 4 | |
| 10 | 10450051 | 挡圈 22 | Ring 22 | 1 | |
| 11 | 10470001 | 销 3.2×20 | Pin 3.2×20 | 2 | |
| 12 | 10470064 | 销 5×36 | Pin 5×36 | 1 | |
| 13 | 10440012 | 垫圈 12 | Washer 12 | 4 | |
| 14 | 10440002 | 垫圈 16 | Washer 16 | 4 | |
| 15 | 10440010 | 垫圈 12 | Washer 12 | 4 | |
