QY16C_70A 中心回转接头 Center Revolving Body
| 序号 | 代号 | 名称 | 数量 | 备注 | |
| № | Part No. | Part Description | Q’ty | Remark | |
| 1 | 10410040 | 螺栓 M12×40 | Bolt M12×40 | 8 | |
| 2 | 10440010 | 垫圏 12 | Washer 12 | 8 | |
| 3 | 10430005 | 螺母 M12 | Nut M12 | 4 | |
| 4 | QY16C.70.1 | 支座 | Support | 1 | |
| 5 | QY16C.70-2A | 固定体 | Fix body | 1 | |
| 6 | QY16K.70-3A | 垫环 | Ring | 1 | |
| 7 | 20130071 | O形圈 142.47×3.53 | O seal ring 142.47×3.53 | 1 | |
| 8 | QY16C.70.3B | 套筒 | Sleeve | 1 | |
| 9 | QY16C.70.4A | 拨叉 | Transmission fork | 1 | |
| 10 | 10430021 | 螺栓 M10×25 | Bolt M10×25 | 4 | |
| 11 | 10440006 | 垫圈 10 | Washer 10 | 4 | |
| 12 | 20130079 | 旋转密封 | Revolving seal | 6 | |
| 13 | QY16K.70-6A | 压板 | Pressing plate | 2 | |
| 14 | 10410011 | 螺栓 M8×20 | Bolt M8×20 | 6 | |
| 15 | 10440001 | 垫圈 8 | Washer 8 | 6 | |
| 16 | QY16C.70.5A | 电刷总成 | Electric brush | 1 | |
| 17 | 10123739 | 接头体 G6 | Gonnection G6 | 1 | |
| 18 | 10123740 | 螺塞 M42×2 | Bolt M42×2 | 1 | |
| 19 | 10123741 | 螺塞 M27×2 | Bolt M27×2 | 4 | |
