JSQF2502.00 驾驶室 Cab
| 序号 | 零部件代号 | 名称 | 数量 | 备注 | |
| No | Part No. | Part Description | Q’ty | Remark | |
| 1 | 10410228 | 螺栓 M16×70 | Bolt M16×70 | 4 | |
| 2 | 10430062 | 螺母 M16 | Nut M16 | 4 | |
| 3 | 10440119 | 垫圈 16 | Washer 16 | 10 | |
| 4 | 10470007 | 销 4×30 | Pin 4×30 | 4 | |
| 5 | 司机椅 | Chair | 2 | ||
| 6 | PW21/52-07027 | 离合器储油壶 | Oil cup | 1 | |
| 7 | PW21/52-07031 | 离合器储油壶支架 | Oil cup supper | 1 | |
| 8 | RDGDX/57-07010 | 防护栏总成 | Protective grating | 1 | |
| 9 | ZXSGD06X1 | 驾驶室焊接总成 | Cab weld assy | 1 | 配OM906LA.E3A/1 |
| 10 | 吊环 | Handing ring | 4 | ||
| 11 | SK1612 | 视廓灯 | Clearance lamp | 2 | |
| 12 | RDGD/52-05010 | 刮水器总成 | Wiper | 1 | |
| 13 | RDGD/82-07120 | 右后视镜支架 | Right reserve mirror support assembly | 1 | |
| 14 | WT-430X220 | 后视镜 | Reverse mirror | 2 | |
| 15 | 0190·R150 | 前下视镜 | Front mirror | 1 | |
| 16 | RDGD/53-07011 | 前挡风玻璃 | Front windshield | 1 | |
| 17 | W160100-1 | 雾灯总成 | Fog light | 2 | |
| 18 | W160100-1 | 远光灯总成 | Beam light | 2 | |
| 19 | RDGD/53-01063 | 左导流罩 | left fairwater | 1 | |
| 20 | AZ9100720011 | 左前照灯总成 | Front left lamp | 1 | |
| 21 | HLD5-Q12-L | 左转向灯总成 | left turning right assembly | 1 | |
| 22 | RDGDX/28-00010 | 保险杠总成 | Bumper assembly | 1 | |
| 23 | RDGDX/53-07110 | 仪表工作台总成 | Instrument panel assembly | 1 | |
| 24 | RDGD/53-07012 | 前挡风玻璃密封条 | Sealing strip | 1 | |
| 25 | RDGD/84-07011 | 左上脚踏板 | Left pedal | 1 | |
| 26 | RDGD/84-07037 | 左挡泥板 | Left dasher | 1 | |
| 27 | RDGD/84-07013 | 左上脚踏板护板 | Pedal sheet | 1 | |
| 28 | RDGD/84-07030 | 左下脚踏板铆接总成 | Pedal sheet | 1 | |
| 29 | PW21/82-00085 | 侧窗扶手总成 | Handrail assembly | 2 | |
| 30 | PW21/82-02051 | 左上支架一外后视镜 | Up left support | 1 | |
| 31 | RDGD/84-07061 | 左翼子板 | Left fender | 1 | |
| 32 | 61N-05079 | 锁芯 | Lock wick | 1 | |
| 33 | RDGD/82-07110 | 左后视镜支架总成 | Left reserve mirror suppport assembly | 1 | |
| 34 | JJ5A-2000Z | 左外开拉手 | Left door handle | 1 | |
| 35 | RDGD/61-07015 | 左车窗玻璃 | Left window glass | 1 | |
| 36 | RDGD/53-07121 | 方向机下左护罩 | Left cleading | 1 | |
| 37 | RDGD/53-07120 | 方向机下右护罩 | Right cleading | 1 | |
| 38 | 3402N-010 | 方向盘 | Steering wheel | 1 | |
