83588200 轮边减速器 Wheel-end
| 序号 | 零部件代号 | 名称 | 数量 | 备注 | |
| No | Part No. | Part Description | Q’ty | Remark | |
| 1 | 83555215 | 挡油板 | Bat | 1 | |
| 2 | 83555213 | 油封座 | Seal oil case | 1 | |
| 3 | 53100040 | 油封 FB190×220×15 | Oil seal FB190×220×15 | 1 | |
| 4 | 53100041 | 油封 B190×220×15 | Oil seal B190×220×15 | 1 | |
| 5 | 83555214 | 防尘罩 | Cover | 1 | |
| 6 | 83555232 | O型密封圈 109×5.7 | Combine washer 109×5.7 | 1 | |
| 7 | 83555227 | 垫片 | Washer | 1 | |
| 8 | 83555212 | 轮辋 | Wheel hub | 1 | |
| 9 | 54100052 | 轴承 32222 | Bearing 32222 | 1 | |
| 10 | 52020002 | 垫圈 8 | Washer 8 | 10 | |
| 11 | 50009003 | 螺栓 M8×16 | Bolt M8×16 | 10 | |
| 12 | 54100060 | 轴承 30222 | Bearing 30222 | 1 | |
| 13 | 79900318 | 磁性螺塞 M22×1.5 | Bolt M22×1.5 | 2 | |
| 14 | 53200008 | 组合密封垫 | Compound seal washer | 2 | |
| 15 | 79605020 | 调整支柱组 | Adjust brace | 1 | |
| 16 | 54930003 | 滚针轴承 K28×40×27 | Bearing K28×40×27 | 10 | |
| 17 | 54800005 | 钢球 8 | Steel ball 8 | 5 | |
| 18 | 83555206 | 隔套 | Sleeve | 5 | |
| 19 | 83555207 | 行星轮轴 | Planet axle | 5 | |
| 20 | 83555204 | 行星轮垫 | Washer | 10 | |
| 21 | 83555205 | 行星轮 | Planet gear | 5 | |
| 22 | 83555218 | 槽螺母 | Nut | 1 | |
| 23 | 83555217 | 垫片 | Washer | 1 | |
| 24 | 83555209 | 行星轮架罩 | Spider cover | 1 | |
| 25 | 53000060 | O型密封圈 250×7 | Combine washer 250×7 | 1 | |
| 26 | 83555216 | 齿圈支承组件 | Supporting assembly | 1 | |
| 27 | 83555226 | 套 | Sleeve | 1 | |
| 28 | 50019008 | 螺检 M12×30 | Bolt M12×30 | 12 | |
| 29 | 54100043 | 轴承 30312 | Bearing 30312 | 2组 | |
| 30 | 83555229 | 油封 B55×70×12 | Oil seal B55×70×12 | 1 | |
| 31 | 83555225 | 太阳轮塾 | Washer | 1 | |
| 32 | 83555203 | 太阳轮 | Sun gear | 1 | |
| 33 | 52100009 | 挡圈 50 | Ring 50 | 1 | |
| 34 | 50140002 | 螺钉 10×25 | Bolt 10×25 | 2 | |
| 35 | 83555230 | 行星轮架组件 | Planet wheel assembly | 1 | |
| 36 | 83555201 | 限位块 | Block | 1 | |
| 37 | 83555202 | 端盖 | Cover | 1 | |
| 38 | 52020003 | 塾圏 10 | Washer 10 | 10 | |
| 39 | 50009012 | 螺检 M10×25 | Bolt M10×25 | 10 | |
