82753600 主减速器 Carrier
| 序号 | 零部件代号 | 名称 | 数量 | 备注 | |
| No | Part No. | Part Description | Q’ty | Remark | |
| 1 | 82468462 | 拨叉 | Fork assembly | 1 | |
| 1 | 82468461 | 拨叉活动块 | Block | 2 | |
| 3 | 82469311 | 弯板 | Board | 1 | |
| 4 | 51014002 | 螺母 M8 | Nut M8 | 1 | |
| 5 | 50151001 | 螺钉 M8×25 | Bolt M8×25 | 1 | |
| 6 | 82468441 | 滑动啮合套 | Tooth cover | 1 | |
| 7 | 82468442 | 圆螺母 | Nut | 1 | |
| 8 | 82468443 | 锁止垫片 | Lock | 1 | |
| 9 | 82468440 | 固定腿合套 | Tooth cover | 1 | |
| 10 | 82423328 | 差速器螺母 | Diff. Nut | 2 | |
| 11 | 54100035 | 轴承 32216 | Bearing 32216 | 2 | |
| 12 | 50009050 | 螺栓 M6×14 | Bolt M6×14 | 2 | |
| 13 | 52020001 | 垫圈 6 | Washer 6 | 2 | |
| 14 | 82423324 | 止动片 | Lock piece | 2 | |
| 15 | 50012022 | 螺栓 M16×1.5×35 | Bolt M16×1.5×35 | 16 | |
| 16 | 82469307 | 锁片 | Lock | 8 | |
| 17 | 82468439 | 差速器壳体 | Diff. | 1 | |
| 18 | 82423318 | 半轴齿轮垫 | Washer | 两组 | |
| 19 | 82423317 | 半轴齿轮 | Gear | 2 | |
| 20 | 82423314 | 行星齿轮垫 | Washer | 4 | |
| 21 | 82423316 | 行星齿轮 | Gear | 4 | |
| 22 | 82423315 | 差速器十字轴 | Cross Axle | 1 | |
| 23 | 82468445 | 开槽螺母 | Nut | 1 | |
| 24 | 82468435 | 主动齿轮 | Pinion | 1 | |
| 25 | 82468436 | 被动齿轮 | Gear | 1 | |
| 26 | 82468446 | 贯通轴 | Axle | 1 | |
| 27 | 54300001 | 轴承 6212 | Bearing 6212 | 1 | |
| 28 | 53510003 | 油封 FB85×105×9 | Oil seal FB85×105×9 | 2 | |
| 29 | 53510004 | 油封 B85×105×9 |
Oil seal B85×105×9 | 2 | |
| 30 | 82423338 | 凸缘螺母 | Nut | 2 | |
| 31 | 51210018 | 开口销 5×60 | Pin 5×60 | 2 | |
| 32 | 82753601 | 连接法兰组件 | Flange | 1 | |
| 33 | 50011029 | 螺栓 M14×1.5×80 | Bolt M14×1.5×80 | 8 | |
| 34 | 82423313 | 差速器壳体 | Diff. | 1 | |
| 35 | 82468429 | 挡油片 | Plate | 1 | |
| 36 | 82468427 | 轴承 | Bearing | 1 | |
| 37 | 82468428 | 钢丝挡圈 | Ring | 1 | |
| 38 | 82468426 | 从动斜齿轮 | Gear | 1 | |
| 39 | 82468419 | 隔套 | Sleeve | 1 | |
| 40 | 51110004 | 双头螺柱 | Bolt | 8 | |
| 41 | 82468422 | 轴承座 | Bearing cage | 1 | |
| 42 | 54100042 | 轴承 31311 | Bearing 31311 | 2 | |
| 43 | 82588414 | 调整垫片 | Adjust washer | 1组 | |
| 44 | 82468423 | 轴承外环压板 | Plate | 1 | |
| 45 | 51031001 | 螺母 M10 | Nut M10 | 8 | |
| 46 | 82468420 | 轴承压板 | Plate | 1 | |
| 47 | 50009024 | 螺栓 M14×30 | Bolt M14×30 | 3 | |
| 48 | 82598401 | 法兰组件 | Flange | 1 | |
| 49 | 52122001 | 挡圈 130 | Ring 130 | 2 | |
| 50 | 54900004 | 轴承 50312 | Bearing 50312 | 2 | |
| 51 | 82468462 | 拨叉 | Fork | 1 | |
| 52 | 82468461 | 拨叉活动块 | Fork block | 2 | |
| 53 | 82468414 | 轴间差速器壳垫片 | Washer | 1 | |
| 54 | 82468416 | 差速锁锁环 | Differential lock ring | 1 | |
| 55 | 82468415 | 差速锁销 | Pin | 10 | |
| 56 | 82468409 | 差速器壳 | Diff. | 1 | |
| 57 | 82468413 | 半轴齿轮垫 | Washer | 1组 | |
| 58 | 82468412 | 半轴齿轮 | Gear | 1 | |
| 59 | 82423315 | 差速器十字轴 | Cross axes | 1 | |
| 60 | 82423316 | 行星齿轮 | Planet gear | 4 | |
| 61 | 82423314 | 行星齿轮垫 | Planet gear washer | 4 | |
| 62 | 82468410 | 半轴齿轮 | Gear | 1 | |
| 63 | 82468411 | 半轴齿轮垫 | Washer | 1组 | |
| 64 | 82468408 | 差速器壳体 | Diff. shell | 1 | |
| 65 | 50011029 | 螺栓 M14×1.5×80 |
Bolt M14×1.5×80 | 8 | |
| 66 | 54900005 | 轴承 60119 | Bearing 60119 | 1 | |
| 67 | 52100018 | 挡圈 95 | Ring 95 | 1 | |
| 68 | 82468444 | 空心轴 | Axle | 1 | |
| 69 | 82468417 | 主动圆柱齿轮 | Gear | 1 | |
| 70 | 57000008 | 气缸 | Crock | 1 | |
| 71 | 82468452 | 差速锁摇臂总成 | Differential lock arm | 1 | |
| 72 | 53000037 | O型密封圈 | Combine washer | 1 | |
| 73 | 82468455 | 衬套 | Sleeve | 1 | |
| 74 | 52100020 | 挡圈 17 | Ring 17 | 1 | |
| 75 | 50160005 | 螺柱 M8×20 | Bolt M8×20 | 1 | |
| 76 | 51014002 | 螺母 M8 | Nut M8 | 1 | |
| 77 | 51014003 | 螺母 | Nut | 1 | |
| 78 | 50009052 | 螺栓 M10×50 | Bolt M10×50 | 1 | |
| 79 | 57000010 | 信号开关 | Switch | 1 | |
| 80 | 57000011 | 塾片 | Washer | 1 | |
| 81 | 82468447 | 销 | Pin | 1 | |
| 82 | 52020003 | 塾圈 10 | Washer 10 | 34 | |
| 83 | 50009013 | 螺栓 M10×25 | Bolt M10×25 | 14 | |
| 84 | 82588408 | 油封座 | Seal oil case | 1 | |
| 85 | 82468460 | 碗形堵塞 | Plug | 1 | |
| 86 | 53200007 | 组合垫圈 36 | Washer 36 | 3 | |
| 87 | 82468418 | 油堵 | Plug | 3 | |
| 88 | 51014003 | 螺母 M10 | Nut M10 | 18 | |
| 89 | 82468405 | 端盖 | Cover | 1 | |
| 90 | 51110005 | 双头螺柱 | Bolt | 18 | |
| 91 | 82468425 | 过桥箱 | Case | 1 | |
| 92 | 51110006 | 双头螺柱 | Bolt | 18 | |
| 93 | 82468433 | 主减速器壳体 | Carrier case | 1 | |
| 94 | 52020004 | 塾圈 12 | Washer 12 | 18 | |
| 95 | 51014004 | 螺母 M12 | Nut M12 | 18 | |
| 96 | 82423339 | 双头螺柱 | Bolt | 4 | |
| 97 | 51270017 | 销 A8×20 | Pin A8×20 | 4 | |
| 98 | 82423327 | 细承座 | Bearing cage | 2 | |
| 99 | 51080005 | 螺母 M16×1.5 | Nut M16×1.5 | 4 | |
| 100 | 51210009 | 开□销 | Pin | 4 | |
| 101 | 82468464 | 轴承座 | Bearing cage | 1 | |
| 102 | 82468465 | 销 10×14 | Pin 10×14 | 4 | |
| 103 | 82468448 | 盖板总成 | Cover | 1 | |
| 104 | 50009011 | 螺栓 N10×20 | Bolt N10×20 | 8 | |
| 105 | 82468456 | 托架总成 | Bracket | 1 | |
| 106 | 50009007 | 螺栓 M8×20 | Bolt M8×20 | 2 | |
| 107 | 52020002 | 垫圈 8 | Washer 8 | 2 | |
| 108 | 52000001 | 垫圈 8 | Washer 8 | 1 | |
| 109 | 51014002 | 螺母 8 | Nut 8 | 1 | |
| 110 | 82468458 | 隔套 | Sleeve | 1 | |
