| 序号 | 零部件代号 | 名称 | 数量 | 备注 | |
| No | Part No. | Part Description | Q’ty | Remark | |
| 1 | 51210018 | 开口销 5×60 | Pin 5×60 | 1 | |
| 2 | 82423338 | 凸緣螺母 | Nut | 1 | |
| 3 | 82589301 | 连接法兰组件 | Flange | 1 | |
| 4 | 82589301 | 油封座组件 | Seal oil case | 1 | |
| 5 | 82423340 | O型密封圈 | Combine washer | 1 | |
| 6 | 82423334 | 轴承座 | Bearing cage | 1 | |
| 7 | 82423329 | 调整垫片 | Washer | 1组 | |
| 8 | 82423330 | 调整垫片 | Washer | 1组 | |
| 9 | 82423307 | 主传动齿轮副 | Pinion. Assembly | 1 | |
| 10 | 82469307 | 锁片 | Lock | 8 | |
| 11 | 50012022 | 螺栓 M16×1.5×30 | Bolt M16×1.5×30 | 16 | |
| 12 | 82468440 | 固定啮合套 | Tooth cover | 1 | |
| 13 | 82468441 | 滑动腿合套 | Tooth cover | 1 | |
| 14 | 82423328 | 差速器螺母 | Nut | 2 | |
| 15 | 54100035 | 轴承 32216 | Bearing 32216 | 2 | |
| 16 | 82468442 | 圆螺母 | Nut | 1 | |
| 17 | 82468443 | 锁止垫片 | Washer | 1 | |
| 18 | 82423325 | 主减壳体组件 | Carrier case | 1 | |
| 19 | 51210009 | 开口销 4×30 | Pin 4×30 | 4 | |
| 20 | 82423324 | 止动片 | Lock piece | 2 | |
| 21 | 52020001 | 垫圈 6 | Washer 6 | 2 | |
| 22 | 50009050 | 螺栓 M6×16 | Bolt M6×16 | 2 | |
| 23 | 82469303 | 差速器总成 | Diff | 1 | |
| 24 | 51270017 | 销 A8×20 | Pin A8×20 | 4 | |
| 25 | 82423303 | 调整垫片 | Adjust washer | 2组 | |
| 26 | 54100040 | 轴承 32315 | Bearing 32315 | 1 | |
| 27 | 52020004 | 塾圈 12 | Washer 12 | 12 | |
| 28 | 50019008 | 螺栓 M12×30 | Bolt M12×30 | 12 | |
| 29 | 54100043 | 轴承 30312 | Bearing 30312 | 2组 | |
