| 序号 | 代号 | 名称 | 数量 | 备注 | |
| № | Code | Part Description | Q’ty | Remark | |
| 1 | 800300073 | 离合器 | Clutch | 1 | JL420IC |
| 2 | 805300091 | 垫圈 10 | Washer 10 | 12 | GB/T898-1988 |
| 3 | 805200048 | 螺母 M10 | Nut M10 | 24 | GB/T6170-2000 |
| 4 | 805000347 | 螺柱 M10×70 | Bolt M10×70 | 12 | GB/T898-1988 |
| 5 | 805000017 | 螺栓 M10×25 | Bolt M10×25 | 4 | GB/T5783-2000 |
| 6 | 805300010 | 垫圈 8 | Washer 8 | 6 | GB/T93-1987 |
| 7 | 805300069 | 垫圈 8 | Washer 8 | 6 | GB/T97.1-2002 |
| 8 | 803000377 | 离合器分泵 | Clutch branch pump | 1 | |
| 9 | 805300024 | 垫圈 14 | Washer 14 | 1 | GB/T93-1987 |
| 10 | 803100665 | 接头体 E10 | Connector E10 | 1 | GB/T3750.2-1983 |
| 11 | 805000576 | 螺栓 M14×1.5 | Bolt M14×1.5 | 1 | GB/T3750.2-1983 |
| 12 | 130200709 | 铜管 Ø8×1-3800 | Copper pipe Ø8×1-3800 | 1 | |
| 13 | 805200157 | 螺母 A8 | Nut A8 | 2 | GB/T5647-1985 |
| 14 | 803100644 | 管套 8 | Clip sleeve 8 | 2 | GB/T5646-1985 |
| 15 | 803000010 | 电磁阀 | Sole№id Valve | 1 | 23JVD3S.1 |
| 16 | 805200045 | 螺母 M8 | Nut M8 | 2 | GB/T6170-2000 |
| 17 | 805000436 | 螺栓 M8×60 | Bolt M8×60 | 2 | GB/T5782-2000 |
| 18 | 135200701 | 弯板 | Bent Plate | 1 | |
| 19 | 805000013 | 螺栓 M16×35 | Bolt M16×35 | 4 | GB/T5783-2000 |
| 20 | 805300011 | 垫圈 16 | Washer 16 | 6 | GB/T93-1987 |
| 21 | 135400561 | 辅助悬挂 | Auxiliary Suspension | 1 | |
| 22 | 800301097 | 变速箱 | Transmission | 1 | S8-120 |
| 23 | 805300013 | 垫圈 16 | Washer 16 | 10 | GB/T97.1-2002 |
| 24 | 805000617 | 螺栓 M16×1.5×25 | Bolt M16×1.5×25 | 2 | GB/T5786-2000 |
| 25 | 805000210 | 螺柱 M10×35 | Studs M10×35 | 12 | GB/T898-1988 |
| 26 | 805300014 | 垫圈 10 | Washer 10 | 12 | GB/T955-1987 |
135200700 变速箱安装 Transmission Install
