135200698 气路阀安装 Air Valve Assembly
| 序号 | 代号 | 名称 | 数量 | 备注 | |
| № | Code | Part Description | Q’ty | Remark | |
| 1 | 130300409 | 脚继动阀安装 | Foot relay valve assembly | 2 | |
| 2 | 805200045 | 螺母 M8 | Nut M8 | 8 | GB/T6170-2000 |
| 3 | 805300010 | 垫圈 8 | Washer 8 | 8 | GB/T93-1987 |
| 4 | 135200152 | 干燥器安装 | Air dryer assembly | 1 | |
| 5 | 805000714 | 螺栓 M10×20 | Bolt M10×20 | 6 | GB/T5783-2000 |
| 6 | 805300014 | 垫圈 10 | Washer 10 | 6 | GB/T93-1987 |
| 7 | 135200151 | 小贮气筒安装 | Air reservoir assembly | 1 | |
| 8 | 130300407 | 手继动阀安装 | Hand relay valve assembly | 1 | |
| 9 | 130300408 | 电磁阀安装 | Sole№id vavle assembly | 1 | |
| 10 | 805000436 | 螺栓 M8×60 | Bolt M8×60 | 2 | GB/T5782-2000 |
| 备注: 此配置用于匹配气路系统无ABS防抱死制动系统的车型 | |||||
