| 序号 | 代号 | 名称 | 数量 | 备注 | |
| № | Code | Part Description | Q’ty | Remark | |
| 1 | 134903039 | 上挡风板 | Top Air Strangler | 1 | |
| 2 | 135200874 | 胶管 | Rubber Hose | 1 | |
| 3 | 801900052 | 喉箍 Ø10-Ø16 | Hoop Ø10-Ø16 | 6 | |
| 4 | 803000754 | 散热器 | Radiator | 1 | |
| 5 | 130200868 | 支架 | Bracket | 1 | |
| 6 | 130200869 | 支架 | Bracket | 1 | |
| 7 | 130201252 | 橡胶垫 | Rubber Cushion | 8 | |
| 8 | 805000349 | 螺栓 M12×50 | Bolt M12×50 | 4 | GB/T31.1-1988 |
| 9 | 805300113 | 垫圈 12 | Washer 12 | 4 | GB/T96.1-2002 |
| 10 | 805200101 | 螺母 M12 | Nut M12 | 4 | GB/T6178-2000 |
| 11 | 805600166 | 销 3.2×18 | Cotter 3.2×18 | 4 | GB/T91-2000 |
| 12 | 805300010 | 垫圈 8 | Washer 8 | 8 | GB/T93-1987 |
| 13 | 805200045 | 螺母 M8 | Nut M8 | 8 | GB/T6170-2000 |
| 14 | 800340535 | 导流板 | Deflecting Plate | 1 | 配上柴 |
| 15 | 805000714 | 螺栓 M10×20 | Bolt M10×20 | 9 | GB/T5783-2000 |
| 16 | 805300014 | 垫圈 10 | Washer 10 | 14 | GB/T93-1987 |
| 17 | 805300017 | 垫圈 10 | Washer 10 | 14 | GB/T97.1-2002 |
| 18 | 134903054 | 下挡风板 | Bottom Air Strangler | 1 | |
| 19 | 805000727 | 螺栓 M10×25 | Bolt M10×25 | 3 | GB/T5783-2000 |
| 20 | 135200876 | 胶管 | Rubber Hose | 2 | |
| 21 | 135201594 | 膨胀水箱支架 | Bracket | 1 | |
| 22 | 136200782 | 膨胀水箱 | Expandion Water Tan | 1 | |
| 23 | 805300030 | 垫圈 6 | Washer 6 | 4 | GB/T93-1987 |
| 24 | 805200053 | 螺母 M6 | Nut M6 | 4 | GB/T6170-2000 |
| 25 | 805000525 | 螺栓 M6×20 | Bolt M6×20 | 4 | GB/T5783-2000 |
| 26 | 135200512 | 胶管 | Rubber Hose | 1 | |
| 27 | 801900055 | 卡箍 Ø22〜Ø32 | Clip Ø22〜Ø32 | 2 | |
| 28 | 805000062 | 螺栓 M10×35 | Bolt M10×35 | 2 | GB/T5783-2000 |
| 29 | 805200048 | 螺母 M10 | Nut M10 | 14 | GB/T6170-2000 |
| 30 | 801900182 | 扎带 150×4 | Bandage 150×4 | 5 | |
| 备注: 此散热器配上柴发动机. | |||||
134902997 散热器 Heat Exchanger
