134900817 变速箱安装 Transmission Install
| 序号 | 代号 | 名称 | 数量 | 备注 | |
| № | Code | Part Description | Q’ty | Remark | |
| 1 | 805000209 | 螺柱 M10×9 | Bolt M10×9 | 12 | GB/T898-1988 |
| 2 | 805000347 | 螺柱 M10×70 | Bolt M10×70 | 12 | GB/T898-1988 |
| 3 | 800300073 | 离合器 | Clutch | 1 | JL420IC |
| 4 | 805300091 | 垫圈 10 | Washer 10 | 16 | GB/T955-1987 |
| 5 | 805200048 | 螺母 M10 | Nut M10 | 28 | GB/T6170-2000 |
| 6 | 805000210 | 螺柱 M10×35 | Bolt M10×35 | 12 | GB/T898-1988 |
| 7 | 805300014 | 垫圈 10 | Washer 10 | 16 | GB/T898-1988 |
| 8 | 800300024 | 变速箱 | Transmission | 1 | |
| 9 | 805300025 | 垫圈 12 | Washer 12 | 10 | JB/T982-1977 |
| 10 | 805300020 | 垫圈 12 | Washer 12 | 9 | GB/T6170-2000 |
| 11 | 805000227 | 螺栓 M12×1.5×25 | Bolt M12×1.5×25 | 8 | GB/T5786-2000 |
| 12 | 134900814 | 支架 | Bracket | 1 | |
| 13 | 130200214 | 斜撑 | Support | 2 | |
| 14 | 805300011 | 垫圈 16 | Washer 16 | 10 | GB/T93-1987 |
| 15 | 805000013 | 螺栓 M16×35 | Bolt M16×35 | 8 | GB/T97.1-2002 |
| 16 | 800100121 | 软垫 | Support | 2 | |
| 17 | 805000020 | 螺栓 M8×30 | Bolt M8×30 | 4 | GB/T5783-2000 |
| 18 | 805200045 | 螺母 M8 | Nut M8 | 4 | GB/T6170-2000 |
| 19 | 805300010 | 垫圈 8 | Washer 8 | 4 | GB/T93-1987 |
| 20 | 805300069 | 垫圈 8 | Washer 8 | 4 | GB/T97.1-2002 |
| 21 | 130200211 | 支架 | Bracket | 1 | |
| 22 | 805300013 | 垫圈 16 | Washer 16 | 8 | GB/T97.1-2002 |
| 23 | 805000038 | 螺栓 M16×40 | Bolt M16×40 | 2 | GB/T5783-2000 |
| 24 | 805200051 | 螺母 M16 | Nut M16 | 2 | GB/T6170-2000 |
| 25 | 805000716 | 螺栓 M12×30 | Bolt M12×30 | 2 | GB/T5783-2000 |
| 26 | 130200709 | 铜管 Ø8×1-3800 | Pipe Ø8×1-3800 | 1 | |
| 27 | 805200157 | 螺母 A8 | Nut A8 | 2 | GB/T5647-1985 |
| 28 | 803100644 | 管套 8 | Pipe Sheath 8 | 2 | GB/T5646-1985 |
| 29 | 803000377 | 离合器分泵 | Clutch Servo Cylinder | 1 | CP1604Ep010 |
| 30 | 805000043 | 螺栓 M10×30 | Bolt M10×30 | 4 | GB/T5783-2000 |
| 31 | 134900820 | 分泵支架 | Clutch Servo Cylinder Bracket | 1 | |
