134900541 前支腿配管 Pipes for Front Outrigger Oil
| 序号 | 代号 | 名称 | 数量 | 备注 | |
| № | Code | Part Description | Q’ty | Remark | |
| 1 | 803000738 | 液压双向锁 | Double-way Lock | 1 | |
| 2 | 805000713 | 螺栓 M10×45 | Bolt M10×45 | 4 | GB/T5783-1986 |
| 3 | 805300014 | 垫圈 10 | Washer 10 | 4 | GB/T93-1987 |
| 4 | 803166495 | 接头体 | Connector | 2 | |
| 5 | 803600771 | 压力继电器 | Hydraulic Pressure Switch | 1 | |
| 6 | 803101105 | 胶管接头 | Rubber Hose Connector | 2 | |
| 7 | 803105413 | 接头体 | Connector | 4 | |
| 8 | 803105530 | 卡套 | Cutting Ferrule | 8 | |
| 9 | 803192986 | 螺母 | Nut | 8 | |
| 10 | 134901020 | 无缝管 Ø12×1.5 | Seamless Pipe Ø12×1.5 | 1 | |
| 11 | 134901021 | 无缝管 Ø12×1.5 | Seamless Pipe Ø12×1.5 | 1 | |
| 12 | 134901023 | 无缝管 Ø12×1.5 | Seamless Pipe Ø12×1.5 | 1 | |
| 13 | 134901022 | 无缝管 Ø12×1.5 | Seamless pipe Ø12×1.5 | 1 | |
| 14 | 803108037 | 管卡 | Clip | 4 | |
| 15 | 803166497 | 接头体 | Connector | 1 | |
