134900350 大梁线束安装 Beam Wires
| 序号 | 代号 | 名称 | 数量 | 备注 | |
| № | Code | Part Description | Q’ty | Remark | |
| 1 | 803704401 | 电子油门踏板 | Accelerator Pedal | 1 | Z505.181/01 |
| 2 | 134901064 | 大梁线束 | Beam Wires | 1 | |
| 3 | 134901065 | 发动机线束 | Engine Wires | 1 | |
| 4 | 130301667 | 支腿油门支架总成 | Leg Control Bracket Assembly | 1 | |
| 5 | 805000017 | 螺栓 M8×25 | Bolt M8×25 | 8 | GB/T5783-2000 |
| 6 | 805300018 | 垫圈 8 | Washer 8 | 8 | GB/T93-1987 |
| 7 | 805300020 | 垫圈 8 | Washer 8 | 8 | GB/T97.1-2002 |
| 8 | 805200049 | 螺母 M8 | Nut M8 | 8 | GB/T6170-2000 |
| 9 | 803700007 | 电喇叭 | Eletric Bugle | 1 | |
| 10 | 805000525 | 螺栓 M6×20 | Bolt M6×20 | 2 | GB/T5783-2000 |
| 11 | 805300030 | 垫圈 6 | Washer 6 | 2 | GB/T93-1987 |
| 12 | 805300029 | 垫圈 6 | Washer 6 | 2 | GB/T97.1-2002 |
| 13 | 805200053 | 螺母 M6 | Nut M6 | 2 | GB/T6170-2000 |
| 14 | 803700116 | H型摄像头 | Camera Shooting | 2 | KC-V8 |
| 15 | 803700113 | 液晶彩色显示器 | Liquid-crystal Display | 1 | |
| 16 | 134901059 | ABS线束 | ABS Wires | 1 | 选装 |
| 17 | 803700539 | ABS控制器 | ABS Controller | 1 | 4S/4M-E |
| 18 | 803704246 | ABS传感器 | ABS Sensor | 4 | |
| 19 | 803700597 | 衬套 | Sensor Bush | 4 | ABS自带 |
| 20 | 803700596 | 润滑脂 | Lubricant | 2 | ABS自带 |
| 21 | 839900081 | 胶带 | Adhesive Tape | 1 | |
| 22 | 822100273 | 波纹管 | Undee Pipe | 1 | EW11 |
| 23 | 859910073 | 尼龙扎带 | Strap | 60 | ZD300X8 |
| 24 | 801901442 | 尼龙扎带 | Strap | 60 | ZD150X3.5 |
| 25 | 803600376 | 电瓶箱至发电机电枢连线 | Battery Box-generator Wires | 1 | |
| 26 | 803600394 | 二芯插头护套 | Two-pin Plug | 2 | DJ7021-6.3-11 |
| 27 | 134903000 | 支腿油门支架总成 | Leg Control Bracket Assembly | 1 | |
| 备注：此部件用于匹配上柴和杭发国III发动机 | |||||
