QY25K5 – 12104876 回转缓沖阀安装总成 Valve For Buffering Assy
| 序号 | 零部件代号 | 名称 | 数量 | 备注 | |
| Sr, No. | Part No. | Part name | Q’ ty | Remark | |
| 1 | 10121073 | 过渡块 | Transition Block | 1 | |
| 2 | 10121074 | 接头 | Fitting | 1 | |
| 3 | 10123815 | 接头体 | Fitting Body | 4 | |
| 4 | 10420007 | 螺钉 M10×30 | Bolt M10×30 | 4 | |
| 5 | 10440006 | 垫圈 10 | Washer 10 | 8 | |
| 6 | 10130107 | 螺塞 M8×1 | Spiral shell stopper M8×1 | 2 | |
| 7 | 10440060 | 垫圈 8 | Washer 8 | 1 | |
| 8 | 10420070 | 螺钉 M10×5 | Bolt M10×5 | 4 | |
| 9 | 10120579 | 管接头 E10 | Fitting Body E10 | 1 | |
| 10 | 10440016 | 垫圈 14 | Washer 14 | 2 | |
| 11 | 10100170 | 回转缓沖阀 | The turning buffers | 1 | |
| 12 | 10123787 | 接头体 | Fitting Body | 1 | |
| 13 | 10121265 | 螺塞 M12×1.5 | Spiral shell stop M12×1.5 | 1 | |
| 14 | 10440017 | 垫圈 12 | Washer 12 | 1 | |
