111204336 起升机构 Lifting Movement
| 序号 | 零部件代号 | 名称 | 数量 | 备注 | |
| Sr, No. | Part No. | Partname | Q’ ty | Remark | |
| 1 | 805000322 | 螺栓 M6×16 | Bolt M6×16 | 6 | GB/T5783-2000 |
| 2 | 805300153 | 垫圈 6 | Washer 6 | 6 | GB/T97.1-2002 |
| 3 | 803000408 | 马达 | Motor | 2 | A6V 80HD1D2FZ20550 |
| 4 | 805000404 | 螺栓 M12×45 | Bolt M12×45 | 12 | GB/T5782-2000 |
| 5 | 805300018 | 垫圈 12 | Washer 12 | 20 | GB/T93-1987 |
| 6 | 800300297 | 卷扬减速机 | Winch | 1 | GJT17W2B45-11 |
| 7 | 805000574 | 螺栓 M12×40 | Bolt M12×40 | 8 | GB/T5782-2000 |
| 8 | 805000410 | 螺栓 M16×55 | Bolt M16×55 | 36 | GB/T5782-2000 |
| 9 | 805300011 | 垫圈 16 | Washer 16 | 36 | GB/T93-1987 |
| 10 | 805000043 | 螺栓 M10×30 | Bolt M10×30 | 8 | GB/T5783-2000 |
| 11 | 805300062 | 垫圈 10 | Washer 10 | 8 | GB/T859-1987 |
| 12 | 805200048 | 螺母 M10 | Nut M10 | 8 | GB/T6170-2000 |
| 13 | 803500378 | 记数器 | Counter | 2 | GF-185 |
| 14 | 805300118 | 垫圈 30 | Washer 30 | 8 | GB/T97.1-2002 |
| 15 | 805600061 | 销 6.3×60 | Pin 6.3×60 | 8 | GB/T91-2000 |
| 16 | 110500370 | 右钢丝绳护罩 | Right Guard Plate | 1 | |
| 17 | 110500846 | 销轴 | Pin Shaft | 4 | |
| 18 | 110500373 | 左钢丝绳护罩 | Left Guard Plate | 1 | |
| 19 | 800301068 | 卷扬减速机 | Winch | 1 | GJT17W2B45-12 |
| 20 | 111202250 | 右钢丝绳护罩 | Right Guard Plate | 1 | |
| 21 | 111202251 | 左钢丝绳护罩 | Left Guard Plate | 1 | |
| 22 | 800300482 | 卷扬减速机 | Winch | 1 | QBL.95B |
| 23 | 800300483 | 卷扬减速机 | Winch | 1 | JQ80.45A |
| 24 | 800300484 | 卷扬减速机 | Winch | 1 | QJB 140.45A |
| 25 | 800301069 | 卷扬减速机 | Winch | 1 | QBL95B2 |
| 26 | 800301070 | 卷扬减速机 | Winch | 1 | JQ80.45A1 |
| 27 | 800301071 | 卷扬减速机 | Winch | 1 | QJB140.45C |
| 28 | 819911637 | 卷扬监视装置 | Winch Monitor | 1 | |
| 29 | 805000714 | 螺栓 M10×20 | Bolt M10×20 | 2 | GB/T5783-2000 |
| 30 | 805300014 | 垫圈 10 | Washer 10 | 2 | GB/T93-1987 |
