111202497 导向轮 Guide Rack
| 序号 | 零部件代号 | 名称 | 数量 | 备注 | |
| Sr, No. | Part No. | Partname | Q’ ty | Remark | |
| 1 | 111202498 | 导向轮结构 | Guide Pulley | 1 | |
| 2 | 111202513 | 滑轮总成 | Pulley | 1 | |
| 3 | 111202514 | 垫圈 | Washer | 2 | |
| 4 | 111202515 | 销轴 | Shaft | 1 | |
| 5 | 111202516 | 挡轴板 | Baffles | 1 | |
| 6 | 111202517 | 滚轮 | Pulley | 2 | |
| 7 | 111202518 | 轴 | Shaft | 1 | |
| 8 | 111202519 | 隔套 | Space | 1 | |
| 9 | 111202520 | 绳挡 | Rope Block | 1 | |
| 10 | 800501028 | 轴承 RS-5018ZZNR | Bearing RS-5018ZZNR | 2 | 进口 |
| 11 | 805002727 | 螺栓 M10×25 | Bolt M10×25 | 2 | GB/T5783-2000 |
| 12 | 805300014 | 垫圈 10 | Washer 10 | 2 | GB/T93-1987 |
| 13 | 805600011 | 销 6.3×45 | Pin 6.3×45 | 1 | GB/T91-2000 |
| 14 | 805600365 | 销 4×32 | Pin 4×32 | 1 | GB/T91-2000 |
