111201462 主臂电气 Boom Electric System
| 序号 | 零部件代号 | 名称 | 数量 | 备注 | |
| Sr, No. | Part No. | Partname | Q’ ty | Remark | |
| 1 | 803600420 | 片形孔式接线片 | Sheet plug | 6 | |
| 2 | 805200046 | 螺母 M5 | Nut M5 | 1 | GB/T6170-2000 |
| 3 | 805300119 | 垫圈 5 | Washer 5 | 1 | GB/T97.1-2002 |
| 4 | 803700549 | 热缩套管 L=15 | Sleeve L=15 | 8 | |
| 5 | 803505904 | 警示灯 | Caution lamp | 1 | |
| 6 | 805100278 | 螺钉 M6×10 | Screw M6×10 | 1 | GB/T818-2000 |
| 7 | 805300029 | 垫圈 6 | Washer 6 | 43 | GB/T97.1-2002 |
| 8 | 803600462 | 圆柱型插头 | Columniform plug | 12 | |
| 9 | 803600459 | 圆柱型插接件护套 | The jacket of columniform plug | 12 | |
| 10 | 803600464 | 圆柱型插座 | Columniform socket | 10 | |
| 11 | 803600460 | 圆柱型插接件护套 | The jacket of columniform socket | 10 | |
| 12 | 111201463 | 支架 | Bracket | 1 | |
| 13 | 803500207 | 长度、角度传感器 | Length and angle sensor | 1 | |
| 14 | 801900028 | 扎带 | Clip strip | 30 | |
| 15 | 803506091 | 工作灯 | Big lamp | 1 | |
| 16 | 839900103 | 塑料套管 L=2m | Sleeve L=2m | 1 | |
| 17 | 111201460 | 吊臂电气焊接图 | Boom electric system welded construction | 1 | 带钢索配重 taked tightwire banlancer |
| 18 | 803600746 | 高度限位开关 | Heigh limit switch | 1 | |
| 19 | 805300014 | 垫圈 10 | Washer 10 | 1 | GB/T93-1987 |
| 20 | 805300017 | 垫圈 10 | Washer 10 | 1 | GB/T97.1-2002 |
| 21 | 805200048 | 螺母 M10 | Nut M10 | 1 | GB/T6170-2000 |
| 22 | 805000322 | 螺栓 M6×16 | Bolt M6×16 | 4 | GB/T5783-2000 |
| 23 | 839900073 | 导线 L=12m | Wire L=12m | 1 | QVR-19/0.26 |
| 24 | 805100211 | 螺钉 M4×10 | Screw M4×10 | 4 | GB/T70.1-2000 |
| 25 | 803601698 | 接线盒总成 | Junction box unit | 1 | |
| 26 | 801900481 | 橡胶套 | Rubber cover | 2 | |
| 27 | 805300030 | 螺钉 M6×12 | Screw M6×12 | 25 | GB/T93-1987 |
| 28 | 111201439 | 拉线支架 | Support | 1 | GB97.1-85 |
| 29 | 819900135 | 套环 | Loop | GB/T5783-2000 | |
| 30 | 803700108 | 卸扣 | Buckle | 1 | |
| 31 | 801300088 | 绳夹 6KTH | Nip 6KTH | 2 | GB/T33-1999 |
| 32 | 801300051 | 压线轮 I | Wheel wire control I | 2 | JB8112-1999 |
| 33 | 801300051 | 压线轮 II | Wheel wire control II | 2 | GB/T5976-1986 |
| 34 | 805300014 | 垫圈 10 | Washer 10 | 4 | |
| 35 | 805000043 | 螺栓 M10×30 | Screw M10×30 | 4 | |
| 36 | 805300017 | 垫圈 10 | Washer 10 | 6 | GB/T93-1987 |
| 37 | 803504415 | 风速仪 | Anemoscope | 1 | GB/T5783-2000 |
| 38 | 805600135 | 销 8×60 | Melt 8×60 | 1 | GB/T97.1-2002 |
| 39 | 803600574 | 盲堵 | Sealed | 5 | AN-60-P-03H-F |
| 40 | 803107884 | 密封 | Airproof | 11 | GB/T91-2000 |
| 41 | 803600572 | 公端子 | Male end | 11 | |
| 42 | 803600458 | 三芯插头 | Three -core plug | 1 | |
| 43 | 803600466 | 六芯插头 | Six -core plug | 1 | |
| 44 | 803600457 | 二芯插头 | Double -core plug | 1 | |
| 45 | 803600575 | 插片 | Insert plake | 1 | |
| 46 | 111204342 | 吊臂线束 | Boom Wires | 1 | |
| 47 | 110701041 | 警灯线束 | Caution lamp wires | 1 | |
| 48 | 805100129 | 螺钉 M6×12 | Screw M6×12 | 15 | |
| 49 | 110700376 | 线卡 | Cover board | 1 | |
| 50 | 111201460 | 吊臂电气焊接位置图 | Boom electric system welded construction | 1 | |
| 51 | 110500674 | 大灯支架 | Workinglamp support | 1 | |
| 52 | 111201444 | 线支架 | Wire support | 4 | |
| 53 | 110700378 | 支架 | Bracket | 1 | |
| 54 | 111201446 | 警灯支架 | Caution lamp support | 1 | |
| 55 | 119100796 | 支架 | Bracket | 1 | |
| 56 | 805300030 | 垫圈 6 | Washer 6 | 40 | |
