111200919 副臂装配总成 Jib Assembly
| 序号 | 零部件代号 | 名称 | 数量 | 备注 | |
| Sr, No. | Part No. | Partname | Q’ ty | Remark | |
| 1 | 110500856 | 销 | Pin | 4 | |
| 2 | 110500800 | 卡子 | Clip | 6 | |
| 3 | 111200920 | 连接架 | Join Frame | 1 | |
| 4 | 110500506 | 滑轮架 | Pulley Wheel Support | 1 | |
| 5 | 110500513 | 副臂结构 | Jib | 1 | |
| 6 | 110500820 | 弹簧销 | Spring pin | 3 | |
| 7 | 110500603 | 滑轮总成 | Pulley assembly | 1 | |
| 8 | 110500873 | 轴 | Shaft | 1 | |
| 9 | 110500604 | 挡板 | Baffle | 2 | |
| 10 | 110500605 | 滑轮总成 | Pulley assembly | 1 | |
| 11 | 110500872 | 销 . | Pin . | 1 | |
| 12 | 110500606 | 挡板 | Baffle | 2 | |
| 13 | 110500879 | 轴套 | Bushing | 2 | |
| 14 | 110800857 | 销轴 | Pin shaft | 1 | |
| 15 | 110500799 | 卡子 | Clip | 1 | |
| 16 | 110500858 | 销轴 | Pin shaft | 2 | |
| 17 | 110500859 | 销轴 | Pin shaft | 2 | |
| 18 | 110500860 | 销轴 | Pin shaft | 1 | |
| 19 | 111200942 | 拉杆 | Pull Board | 1 | |
| 20 | 110500611 | 垫板 | Plate | 1 | |
| 21 | 805600109 | 销 B20×80 | Pin B20×80 | 1 | GB/T882-2008 |
| 22 | 805000525 | 螺栓 M6×20 | Bolt M6×20 | 6 | GB/T5783-2000 |
| 23 | 805300030 | 垫圈 6 | Washer 6 | 6 | GB/T93-1987 |
| 24 | 805600274 | 销 6.3×63 | Pin 6.3×63 | 5 | GB/T91-2000 |
| 25 | 805300021 | 垫圈 24 | Washer 24 | 2 | GB/T97.1-2002 |
| 26 | 805600107 | 销 25×140 | Pin 25×140 | 1 | GB/T880-2008 |
| 27 | 805600108 | 销 B20×100 | Pin B20×100 | 2 | GB/T882-2008 |
| 28 | 805300112 | 垫圈 20 | Washer 20 | 2 | GB/T97.1-2002 |
| 29 | 805000714 | 螺栓 M10×20 | Bolt M10×20 | 4 | GB/T5783-2000 |
| 30 | 805300014 | 垫圈 10 | Washer 10 | 4 | GB/T93-1987 |
| 31 | 805300047 | 垫圈 36 | Washer 36 | 5 | GB/T97.1-2002 |
| 32 | 801100336 | 油杯 M10×1 | Oil cup M10×1 | 2 | JB/T7940.1-1995 |
