110501098 副臂电气 Jib Electric System
| 序号 | 零部件代号 | 名称 | 数量 | 备注 | |
| Sr, No. | Part No. | Partname | Q’ ty | Remark | |
| 1 | 805200048 | 螺母 M10 | Nut M10 | 1 | GB/T6170-2000 |
| 2 | 805300017 | 垫圈 10 | Washer 10 | 1 | GB/T97.1-2002 |
| 3 | 805300014 | 垫圈 10 | Washer 10 | 1 | GB/T93-1987 |
| 4 | 803600746 | 重锤式齐整高度限制器 | Switch | 1 | |
| 5 | 819900406 | 吊环 | Ring | 1 | |
| 6 | 801900040 | 扎带 | Clip strip | 10 | |
| 7 | 803505904 | 警示灯 | Caution lamp | 1 | |
| 8 | 805200046 | 螺母 M5 | Nut M5 | 2 | |
| 9 | 805300119 | 垫圈 5 | Washer 5 | 1 | |
| 10 | 803600320 | 一节副臂电缆总成 | Jib boom binded wire I | 1 | |
| 11 | 801900037 | 扎带 | Clip strip | 50 | |
| 12 | 副臂电气焊接件位置图 | Jib electric system welded construction | 1 | ||
