QY25K5 – 10100745 伸缩油缸 I Telescoping cylinder I
| 序号 | 零部件代号 | 名称 | 数量 | 备注 | |
| Sr, No. | Part No. | Part name | Q’ ty | Remark | |
| 1 | 12103169 | 导向套 | Front Cover | 1 | |
| 2 | 12104877 | 隔套 | Sleeve | 1 | |
| 3 | 12104878 | 缸筒 | Cylinder | 1 | |
| 4 | 12104879 | 活塞杆 | Rod | 1 | |
| 5 | 12104880 | 通油管 | Vitta | 1 | |
| 6 | 12104400 | 前隔套 | Front Sleeve | 1 | |
| 7 | 12103173 | 活塞 | Piston | 1 | |
| 8 | 12103178 | 导向套 | Front Cover | 1 | |
| 9 | 12104388 | LBH型防尘圈 | Series Wiper | 1 | |
| 10 | 12102466 | O型圈 120×5.7 | O Ring 120×5.7 | 2 | |
| 11 | 12103249 | O型圈 54.4×3.1 | O Ring 54.4×3.1 | 4 | |
| 12 | 12103179 | 斯特封 d38×49×4.2 | Assembled Seal d38×49×4.2 | 2 | |
| 13 | 12103168 | O型圈 175×5.7 | O-Ring 175×5.7 | 2 | |
| 14 | 12100882 | O型圈 50×3.1 | O-Ring 50×3.1 | 1 | |
| 15 | 10100004 | 平衡阀 | Counterbalance valve | 1 | |
