06002267 四节臂 4 th Section Boom
| 序号 | 代号 | 名称 | 数量 | 备注 | |
| № | Part No. | Part Description | Q’ty | Remark | |
| 1 | 06002268 | 四节臂结构 | 4 th Section Structure | 1 | |
| 2 | 06002282 | 滑轮总成 | Pulley Assembly | 4 | |
| 3 | 06002283 | 隔垫 | Sleeve | 3 | |
| 4 | 06002284 | 套 | Sleeve | 2 | |
| 5 | 11421180 | 轴 | Shaft | 1 | |
| 6 | 06002285 | 套 | Sleeve | 1 | |
| 7 | 06002286 | 套 | Sleeve | 1 | |
| 8 | 06002287 | 套 | Sleeve | 1 | |
| 9 | 06002288 | 塑板 | Plate | 2 | |
| 10 | 11421181 | 轴 | Shaft | 1 | |
| 11 | 06002289 | 垫板 | Plate | 2 | |
| 12 | 11421182 | 滑块 | Slider | 2 | |
| 13 | 06002125 | 导向滑轮 | Oriented Poller | 2 | |
| 14 | 08402251 | 绳挡 | Rope Seat | 1 | |
| 15 | 01801307 | 绳挡 | Rope Seat | 1 | |
| 16 | 11412835 | 弹簧销 | Spring Pin | 6 | |
| 17 | 01801160 | 垫片 | Mat | 2 | |
| 18 | 01801319 | 板 | Plate | 4 | |
| 19 | 11414276 | 导轨 | Track | 2 | |
| 20 | 11418551 | 销轴 | Pin Shaft | 2 | |
| 21 | 11412840 | 滑块 | Slide | 2 | |
| 22 | 01801320 | 板 | Plate | 4 | |
| 23 | 01200252 | 档轴板 | Plate | 4 | |
| 24 | 11412839 | 滑块 | Slider | 2 | |
| 25 | 01801293 | 绳档 | Rope Seat | 1 | |
| 26 | 01801306 | 盖板 | Plate | 1 | |
| 27 | 01801159 | 垫板 | Plate | 2 | |
| 28 | 10440062 | 垫圈 8 | Washer 8 | 2 | |
| 29 | 10440010 | 垫圈 12 | Washer 12 | 8 | |
| 30 | 10440001 | 垫圈 8 | Washer 8 | 2 | |
| 31 | 10810006 | 油杯 M10×1 | Oil cup M10×1 | 4 | |
| 32 | 10420180 | 螺钉 M8×35 | Bolt M8×35 | 2 | |
| 33 | 10420079 | 螺钉 M8×25 | Bolt M8×25 | 6 | |
| 34 | 10420160 | 螺钉 M8×50 | Bolt M8×50 | 2 | |
| 35 | 10420004 | 螺栓 M12×25 | Bolt M12×25 | 8 | |
| 36 | 10410026 | 螺栓 M8×16 | Bolt M8×16 | 2 | |
