01300432 平衡重电气 Counterweight Electric System
| 序号 | 代号 | 名称 | 数量 | 备注 | |
| № | Part No. | Part Description | Q’ty | Remark | |
| 1 | 12103917 | 平衡重穿线管焊接图 | Counterweight welded construction | 1 | |
| 2 | 12103918 | 片式插接件插头 | Sheet plug | 6 | |
| 3 | 12103919 | 片形插接件护套 | The jacket of Sheet plug | 3 | |
| 4 | 12103920 | 片形插座 | Sheet socket | 6 | |
| 5 | 12103921 | 片形插接件护套 | The jacket of Sheet plug | 3 | |
| 6 | 10230040 | 片形孔式接头 | Sheet plug | 2 | |
| 7 | 11211006 | 扎带 | Clip strip | 10 | |
| 8 | 30249130 | 塑料套管 L=4m | Sleeve L=4m | 1 | |
| 9 | 30249014 | 汽胶线 L=10m | Line L=10m | 1 | |
| 10 | 10200075 | 后示廓灯 | Back wide light | 2 | |
| 11 | 30249014 | 汽胶线 L=10m | Line L=10m | 1 | |
| 12 | 10410374 | 螺栓 M6×16 | Bolt M6×16 | 4 | |
| 13 | 10440021 | 垫圈 6 | Washer 6 | 4 | |
| 14 | 10420222 | 螺钉 M6×10 | Screw M6×10 | 2 | |
| 15 | 10440022 | 塾圈 6 | Washer 6 | 2 | |
